Dorr SnapShot Mini Black 30MP 4K Bruksanvisning
Dorr
fotokamera
SnapShot Mini Black 30MP 4K
Les nedenfor 📖 manual på norsk for Dorr SnapShot Mini Black 30MP 4K (14 sider) i kategorien fotokamera. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/14
doerr-outdoor.de
SNAPSHOT
MINI BLACK 30MP 4K
SURVEILLANCE CAMERA
INSTRUCTION MANUAL
GB
doerr-outdoor.de2
INDEX PAGE
01 |
SAFETY HINTS
3
02 |
SAFETY HINTS FOR BATTERIES
4
03 | PRIVACY POLICY 4
04 | NOMENCLATURE 4
05 | ILLUSTRATION OF PARTS 5
06 | FIRST COMMISSIONING 6
06.1 Inserting the batteries 6
06.2 Changing the batteries 6
06.3 Alternative power supplies 6
06.4 Inserting the SD/SDHC/SDXC Memory Card 6
07 | OPERATION 7
07.1 Overview home screen 7
07.2 All basic factory settings 7
07.3 Main Menus 7
07.4 Menu navigation 7
08 | SETTINGS & FUNCTIONS 8
08.1 Main Menu CAM 8
08.2 Main Menu PIR 9
08.3 Main Menu SYS 10
09 | TEST RECORDINGS 11
10 | MOUNTING · DIRECTING · ACTIVATING 11
10.1 Mounting and directing the camera 11
10.2 Turn on camera and start surveillance 11
10.3 Notes for mounting the camera 11
10.3.1 PIR Sensor 11
10.3.2 Light conditions 11
10.3.3 Weather protection 11
11 | OPTIONAL ACCESSORIES 12
11.1 Optional mounting accessories 12
11.2 Optional anti-theft devices 12
12 | PLAY & DELETE FILES 12
12.1 View photos 12
12.2 Slideshow 12
12.3 Play videos 12
12.4 Delete files 12-13
12.5 Transferring files to a PC 13
13 | CLEANING AND STORAGE 13
14 | TECHNICAL SPECIFIATIONS 13
15 | SCOPE OF DELIVERY 14
16 | DISPOSAL, CE MARK 14
16.1 Disposal of batteries/accumulators 14
16.2 WEEE Information 14
16.3 RoHS Conformity 14
16.4 CE Mark 14
doerr-outdoor.de3
01 | SAFETY HINTS
•
Your camera is fitted with a weatherproof housing according to
protection class IP66 (dust and jet waterproof) so that the camera
can be used outdoors. Nevertheless, protect the camera from
extreme weather conditions and direct sunlight.
•
Caution! Make sure to use only fresh Mignon AA LR6 1.5V Alkaline
Manganese batteries of the same type and brand. When inserting
the batteries please respect the correct polarity (+/-). Please
remove batteries when device is not in use for a longer period.
•
Do not use rechargeable batteries. They may lead to malfunction.
•
Only use SD/SDHC/SDXC memory cards from 4GB up to max.
256GB. Using a micro SD card in combination with an adapter may
lead to malfunctions.
•
Do not drop the camera onto a hard surface. Do not use the camera
if it has been dropped. In this case a qualified electrician should
inspect the camera before you use it again.
•
Do not attempt to repair the devise by yourself. Risk of electrical
shock! When service or repair is required, contact qualified service
personnel.
•
Do not open the camera housing (except the housing lid and the
battery compartment) – the warranty will become void. The housing
may only be opened by qualified DÖRR GmbH staff.
•
LED bulbs can only be replaced by qualified DÖRR GmbH staff.
•
This device is not a toy! To prevent accidents and suffocation
keep the device, the accessories and the packing materials away
from children and pets.
•
People with physical or cognitive disabilities should use the camera
with supervision.
•
People with cardiac pacemakers, defibrillators or any other elect-
rical implants should maintain a minimum distance of 30 cm, as the
device generates magnetic fields.
•
Do not use the camera nearby devices that generate strong electro-
magnetic fields.
•
Avoid touching the camera lens with your fingers.
•
Protect the camera against extensive dirt. Never use aggressive
cleansing agents or benzine to clean the camera. We recommend
a soft, slightly damp microfiber cloth to clean the outer parts of
the camera and the camera lens. Make sure to remove batteries
before cleaning.
•
Store the camera in a dust-free, dry and cool place when not in use.
•
If the device is defective or without any further use, dispose of the
device according to the Waste Electrical and Electronic Equipment
Directive WEEE. For further information, please contact your local
authorities.
GB
THANK YOU very much for choosing a quality product by DÖRR.
Please read the instruction manual and the safety hints carefully
before using the device for the first time.
Keep the operating instructions together with the device for referen-
ce. If other people use this device, provide them with these instruc-
tions. If you sell the unit, this manual forms an integral part of the
device and must be supplied with it.
DÖRR is not liable for damage caused by improper use or failure to
observe the operating and safety instructions.
In the event of damage caused by improper handling or by external
influence, the guarantee or warranty claim becomes void. Any ma-
nipulation, structural modification of the product or opening of the
housing by the user or an unauthorised third party shall be considered
improper handling.
Produkspesifikasjoner
| Merke: | Dorr |
| Kategori: | fotokamera |
| Modell: | SnapShot Mini Black 30MP 4K |
