Quick Start Guide

Version: 1.0

F/W: V1.2.0_RC1b

Date: December 11, 2017

Warranty

We warrant to the original end user (purchaser) that the access point will be free from any defects in workmanship or materials for a period of two

(2) years from the date of purchase from the dealer. Please keep your purchase receipt in a safe place as it serves as proof of date of purchase.

During the warranty period, and upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials,

we will, at our discretion, repair or replace the defective products or components, without charge for either parts or labor, to whatever extent we

deem necessary tore-store the product to proper operating condition. Any replacement will consist of a new or re-manufactured functionally

equivalent product of equal value, and will be offered solely at our discretion. This warranty will not apply if the product is modified, misused,

tampered with, damaged by an act of God, or subjected to abnormal working conditions. The warranty does not cover the bundled or licensed

software of other vendors. Defects which do not significantly affect the usability of the product will not be covered by the warranty. We reserve the

right to revise the manual and online documentation and to make changes from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

Declaration of Conformity

Hereby, DrayTek Corporation declares that the radio equipment type VigorAP 920R is in compliance with Directive 2014/53/EU.

The full text of the EU Declaration of Conformity is available at the following internet address:

https://www.draytek.com.tw/ftp/VigorAP 920R/Document/CE/

Manufacturer: DrayTek Corp.

Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu, Taiwan 303

Product: VigorAP 920R/920RP/920RPD

Frequency Information for Europe area:

2.4G WLAN

2412MHz - 2472 MHz, max. TX power: 19.5dBm

5G WLAN

5470MHz - 5725 MHz, max. TX power: 28.0dBm

Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/ CY/LV/LI/LT/ LU/HU/MT/

NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/ UK/HR. 5150MHz~5350MHz is for indoor use only.

This product is designed for 2.4GHz/5GHz WLAN network throughout the EC region.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one of the following measures:

⚫ Reorient or relocate the receiving antenna.

⚫ Increase the separation between the equipment and receiver.

⚫ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

⚫ Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause undesired operation.

The antenna/transmitter should be kept at least 20 cm away from human body.

Please inspect the package contents. If anything is missing or damaged, please contact

DrayTek or your dealer immediately.

Main Unit

Antennas

Ethernet Cable (3M)

Quick Start Guide

Ground Cable

Mount Kit

Note

Do not use Ethernet cables with molded hood boot.

Produkspesifikasjoner

Merke:	Draytek
Kategori:	Ikke kategorisert
Modell:	VigorAP 920RP
Bredde:	160 mm
Dybde:	80 mm
Høyde:	255 mm
Sertifisering:	CE
Nettverksstandard:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3az
Antall brukere:	128 bruker(e)
DHCP-server:	Ja
MIMO-type:	Multi User MIMO
Maksimal dataoverføringshastighet:	1000 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Virtuelle LAN-funksjoner:	SSID-based VLAN assignment
Brukerbasert båndbreddebegrensning:	Nei
Rask roaming:	Ja
DHCP-klient:	Ja
Maksimal dataoverføringshastighet (5 GHz):	867 Mbit/s
Syslog:	Ja
Wi-Fi-roaming:	Ja
Airtime Fairness (ATF):	Ja
Produktfarge:	Hvit
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-40 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 85 °C
tilbakestillingsknapp:	Ja
Internasjonal beskyttelses (IP)-kode:	IP67
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	802.1x RADIUS, HTTPS, SNMP, WEP, WPA, WPA-PSK, WPA2-PSK, WPS
Relativ luftfuktighet under drift (H-H):	5 - 95
Strøm over Ethernet (PoE):	Ja
MIMO:	Ja
Antall SSID-støtte:	4
SSID-funksjoner:	SSID-sending av/på
