www.drivemedical.com
premium seat rizer
with removable arms
rizer para asiento premium
con brazos removibles
siège surélévateur de wc
premium a poignées
amovibles
item # 12402
www.drivemedical.com
1. Remove product from carton and READ ALL
INSTRUCTIONS CAREFULLY before aempting to
install product.
2. If installation of arms is desired:
a. Place one arm at a time into the arm holes on the
raised toilet seat (the brass buons on the arm
should be facing out, away from the toilet seat.)
b. Depress the brass buon in the front of the arm
while sliding the arm into position. You will hear a
click” when the buon is positioned properly.
(You will see the brass buon pop through the
position hole.)
c. Repeat process for back of arm.
d. Repeat process for the other arm.
e. To remove the arm, depress the brass buon while
pulling up on the arm. Repeat for the back of
the arm.
3. Remove existing toilet seat and lid from toilet.
4. Position raised toilet seat correctly on rim of toilet
bowl and center as necessary.
5. Aach original toilet seat to toilet bowl so it is
positioned over raised toilet seat.
6. Check for secure fit routinely before using product.
User’s weight should be centered over toilet seat, not
too forward or too far to one side, as unit may tip.
7. If you have a style of commode that this product will
not fit properly, it is recommended that you
discontinue use.
cleaning instructions
1. Use a non-abrasive detergent or household cleaner
with warm water.
2. Rinse with warm water and wipe dry.
3. DO NOT USE AN ABRASIVE CLEANER OR CLOTH
with this product, as damage may ensue.
caution
1. Always be sure that the seat is correctly and securely
in place before using.
2. Physically challenged users should be supervised or
assisted whenever using this product.
3. This product is designed for use with the most
common types of commodes. It will not fit all
commode types; be sure that the unit is correctly
installed, fits properly and is stable before use.
instrucciones de instalación
1. Retire el producto de la caja y LEA TODAS LAS
INSTRUCCIONES CUIDADOSAMENTE antes de
intentar instalar el producto.
2. Si se desea instalar los brazos:
a. Coloque un brazo por vez dentro de los orificios
para los brazos en el asiento de inodoro levantado.
(Los botones de metal del brazo deben estar
mirando hacia afuera, alejados del asiento del
inodoro).
b. Baje el botón de metal en el frente del brazo
mientras desliza este último a su posición.
Escuchará un “chasquido” cuando el botón esté
posicionado adecuadamente. (Usted verá que el
botón metálico sale a través del orificio de
posición).
c. Repita el proceso para la parte posterior del brazo.
d. Repita el proceso para el otro brazo.
e. Para quitar el brazo, deprima el botón de metal
mientras tira del brazo hacia arriba. Repita el
proceso para la parte posterior del brazo.
3. Quite el asiento y la tapa existentes del inodoro.
4. Ubique el asiento elevado para inodoro
correctamente sobre el borde del inodoro y proceda
a centrarlo como sea necesario.
5. Coloque el asiento original del inodoro en el mismo
de manera tal que quede ubicado sobre el asiento
elevado para inodoro.
6. Controle rutinariamente que la instalación esté firme
antes de usar el producto. El peso del usuario debe
centrarse sobre el asiento para inodoro, ni
demasiado hacia delante ni demasiado hacia un
costado, dado que la unidad puede inclinarse.
7. Si usted tiene un estilo de taza de inodoro al cual este
producto no se adaptará de la manera adecuada, se
recomienda que deje de usarlo.
instrucciones de limpieza
1. Use un detergente no abrasivo o un limpiador para el
hogar con agua tibia.
2. Enjuague con agua tibia y seque con un paño.
3. NO USE UN LIMPIADOR O TOALLA ABRASIVA con
este producto dado que puede dañarlo.
precaución
1. Asegúrese siempre que el asiento esté correcta y
firmemente ubicado antes de usarlo.
2. Los usuarios sicamente discapacitados deben
ser supervisados o asistidos cada vez que usan este
producto.
3. Este producto está diseñado para uso con los tipos
más comunes de tazas de inodoro. No se adaptará
a todos los tipos de tazas de inodoro. Asegúrese
que la unidad está correctamente instalada, se
adapta apropiadamente y es estable antes de usarla.
