Side 1/4
The CRYBABY
®
has been a standard in the world
of music since its introduction in the late 1960's. Its
rugged construction and efficient design will give
years of outstanding performance.
OPERATING INSTRUCTIONS
•
pedal, you can change the effect that the
CRYBABY
®
has on the tone of your instrument
instantaneously. Toe down will give you more
treble, heel down will give you more bass. The
speed and amount of effect you use depends on
your style of playing.
•
When placing the pedal in one position, you will
hear a boost in that particular frequency. This
boost can be used to add sustain and create
feedback of a desired overtone.
TIPS
•
Listen to the classic recordings of Jimi Hendrix
and Eric Clapton where the CRYBABY
®
is used
extensively. After listening to the sound you will
begin to recognize the CRYBABY
®
in just about
every rock player's repertoire.
•
When using a lot of distortion, the effect will not
be as prominent. Try setting the pedal in one
position. This will help in making artificial
harmonics and controlling the amount of feedback.
CRYBABY
®
SET-UP INSTRUCTIONS
1. Insert a 9 volt battery and/or plug in AC
Adapter. The CRYBABY
®
will operate on either
power source.
Notice: This unit is shipped from the factory
without a battery to prevent possible damage
from leakage. A 9-volt transistor radio battery
must be installed for operation if an AC adapter
is not going to be used. We recommend a high
quality alkaline battery. The adapter jack
requires a 5.5/2.1mm coax plug. Most standard
9VDC AC adapters with greater than 20ma
current capability will work.
To install the battery, remove 4 screws from
the rubber feet securing the bottom cover and
insert the battery.
2. Run a cord from your instrument to the
CryBaby's Instrument jack.
3. Run another cord from your amplifier input
into the CryBaby's Amplifier jack.
4. Turn on the amplifier and begin playing.
5. To turn the pedal on, push the toe of the
pedal down again, until you feel another "click".
Jimi's preferred hookup was: Guitar to Fuzz to
CRYBABY® to Amplifier.
BATTERY
P.C. BOARD
Box 846 Benicia CA 94510 USA
–
+
Plug Polarity DC in 9 volts
FUZZ
CRYBABY
AMP
Warranty becomes effective only when Dunlop Manufacturing receives this
registration card within fourteen (14) days of original purchase. Card must
be filled out completely and signed by the owner.
MAIL THIS SIDE TO DUNLOP MFG. INC.
Detach here
LIMITED WARRANTY
Your Name
Street
City, State, Zip
Telephone
Purchased from (Store Name)
Street
City, State, Zip
Date of Purchase
Signature of Owner X
Customer Survey (Please fill in)
I am: Professional Amateur
Kind of music I play
I purchased because
My purchase price was
JH-1 Hendrix Wah Wah
JH-1S Hendrix Wah Wah Special
JH-1FW Hendrix Fuzz Wah
JH-F2 Dallas Arbiter FuzzFace
JH-2S Hendrix System Fuzz
JH-3S Hendrix Octave Fuzz
JH-4S Rotovibe™
GCB-95 CRYBABY
®
Wah Wah
GCB-95FW CRYBABY
®
Fuzz Wah
GCB-95O CRYBABY
®
Octave Wah
GCB-100 Bass CRYBABY
®
EW-95V Mr. CRYBABY
®
Super
CB535 CRYBABY
®
535-CHROME
BB535 CRYBABY
®
535-BLACK
CR-1S CRYBABY Rack Mount
GCB-80 Highgain Volume
GCB-81 Highgain Vol & Boost
TVP-1 Tremelo/Volume Plus
TS-1 Tremelo Stereo
HT-1 Heil
®
Talkbox
M101 MXR
®
Phase 90
M102 MXR
®
Dyna Comp
M103 MXR
®
Blue Box
M104 MXR
®
Distortion+
M107 MXR
®
Phase 100
M109 MXR
®
6B Graphic EQ
M133 MXR
®
Micro Amp
UV-1 Uni-Vibe
®
UV-1FC Uni-Vibe
®
Foot Controler
Other
Type of Pedal (Check One)
Dunlop Manufacturing is interested in developing products to
fill your needs. If you have a product suggestion or need, please
make your comments below.
Serial Number
NAME
ADDRESS
CITY, STATE & ZIP
•
•
•
•VISA •
•
•
•MASTERCARD •
•
•
•CHE (Payable to Dunlop Mfg., Inc.)CK/ EY ORDER MON
CARD ACCT. #:
SIGNATURE:
PHONE NUMBER:
TOTAL AMOUNT FOR GOODS
TAX FOR CALIFORNIA RESIDENTS 7.375%
SHIPPING CHARGES $6.25
TOTAL
TOTALDESCRIPTIONPAYMENT INFORMATION
Dunlop Manufacturing, Inc.
PO Box 846, Benicia, CA 94510
Tel: 707-745-2722
Fax: 707-745-2658/707-745-2671
EXP. DATE:
QTY UNIT PRICE
92500809147
NOTICE: If mailing from outside the U.S. you must
use a separate envelope and correct postage.
BUSINESS REPLY MAIL
FIRST-CLASS MAIL PERMIT NO. 47 BENICIA, CA
POSTAGE WILL BE PAID BY ADDRESSEE
The Ultimate Crybaby Wah-Wah
Technique and Instruction Manual
To order this First Edition
9"x12" copy of The Wah-
Wah Book, please fill out
the information on the back
side of this card.
F O R S A L E I N
N O R T H A M E R I C A O N L Y !
Since its introduction in the late 60’s, the Wah-Wah has
become the most stepped on pedal of all time. The Wah-
Wah Book has it all: history, technique, perspectives,
philosophy, product information and some great music!
Replacement Parts / Accessories
ECB - 02
ECB - 03
ECB - 04
ECB - 18
ECB - 24
ECB - 24A
EBC - 24B
ECB - 24EW
ECB - 25G
ECB - 69
ECB - 115
ECB - 124
ECB - 126
ECB - 127
ECB - 130
ECB - 140
ECB - 151
ECB - 156
ECT - 305
ECT - 325
ECM - 555
DCR - 1SC25
AC Adapter 9VDC AC 3.5mm Positive Tip Plug
AC Adapter 9VDC AC 5.5/2.1mm Coax Plug
AC Adapter 18VDC AC 5.5/2.1mm Coax Plug
1/4" Stereo Jack "INST IN" PC Mountable
CRYBABY Hot Potz 100K with Gear
470K OHM Audio Pot (GCB80, 81& JH1S Model)
CRYBABY Hot Potz II with Gear
Mr. Crybaby Dual Hot Potz (EW95V Model)
CRYBABY PC Board Jacks Mounted - ECB-03 Jack
CRYBABY ON/OFF Switch
CRYBABY Bottom Plate
CRYBABY Offset Grommets
Gear
Rack
Knob
ROTOVIBE Switch
4 Rubber Feet w/ Screw
CRYBABY 500 MH Inductor
TALKBOX Diaphragm
TALKBOX Tube 6.5' Length
MXR Switch
CRYBABY RACK Stereo Cable 25' Length
ECB -03 5.5/2.1mm coax plug. 9VDC regulated AC adapter
Plug Polarity DC in 9 Volts
ECB-02 Positive tip, 3.5 mm plug.
9VDC regulated AC adapter
AC ADAPTER SPECIFICATIONS
–
+
$14.97
14.97
23.97
3.96
34.98
26.98
26.98
50.00
30.00
13.47
9.00
1.50
1.50
1.50
2.10
15.00
2.46
15.00
75.00
12.00
21.00
31.98
ONLY
$9.95
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
ECB -04 5.5/2.1mm coax plug. 18VDC regulated AC adapter
Plug Polarity DC in 18 Volts
–
+
Included are note-for-note transcriptions and playing tips
of great Wah-Wah solos by Jimi Hendrix, Eric Clapton,
Stevie Ray Vaughan, Randy Rhoads, Slash, Kirk Hammett,
Mike McCready, Zakk Wylde, Eddie Van Halen and others.
Worlds Greatest Music Accessories!
DUNLOP MANUFACTURING INC.
P.O. BOX 846
BENICIA, CA 94510-9837
DUNLOP MANUFACTURING, INC.
P.O. BOX 846, BENICIA, CA 94510 U.S.A.
