DVDO-USBC-HDMI-PS-51
Seamless Switcher / Scaler / Extender
With USB-C & HDMI Inputs & Dante
DVDO │ +1.408.213.6680 │ support@dvdo.com │ www.dvdo.com
User Manual
Version v1.0
Thank you for purchasing DVDO-USBC-HDMI-PS-51
For optimum performance and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
DVDO-USCB-HDMI-PS-51 contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is
highly recommended in order to protect and extend the life of your equipment.
Caution
DVDO-USCB-HDMI-PS-51 requires the use of UTP connectors. Please connect in direct
interconnection method and do not cross connect.
White and Orange
Orange
White and Green
Blue
White and Blue
Green
White and Brown
Brown
Direct Interconnection Method
Table of Contents
1. Introduction. ....................................................................................................................
1
2. Features. ..........................................................................................................................
1
3. Package Contents. ........................................................................................................
1
4. Specifications. ................................................................................................................
2
5. Operation Controls and Functions. ...............................................................................
4
5.1 Switch Panel. .............................................................................................................
4
5.2 HDBaseT Receiver Panel ..........................................................................................
6
5.3 IR Cable Pin Assignment ..........................................................................................
8
6. IR Remote .......................................................................................................................
8
7. Web GUI User Guide ......................................................................................................
9
8. Dante Web GUI User Guide ...........................................................................................
18
9. RS-232 Control Commands ...........................................................................................
21
10. Connection Diagram. ..................................................................................................
35
