Dr. DMX II
USER'S MANUAL
Web site: www.elationlighting .com
E-mail: info@elationlighting.com
1
_General Information
Introduction
Thank you for purchasing the Dr. DMXII.
selector wheel can be used to select the 8 mainly menus. You can also test the DMX packet and
cable, which will catch whether there are errors. The received DMX data can also be displayed
and transmitted, complying with the your settings. If you would like to know more, please read
the user's instruction carefully, and keep it for future reference.
Unpacking
This unit has been thoroughly tested and carefully packed. Please check contents and packing
carefully to be sure that your product is not damaged and all accessories are accounted for. If your
product happens to be damaged or missing parts, please do not use it. Please contact
Elation Professional.
Safety Instructions
To reduce the risk of electric shock or fire when using this unit:
Do not immense in or expose to water.
Turn off the unit, if it will not be used for a long time.
Do not use in the event of a malfunction.
Do not dismantle or modify the unit.
_Specifications
Model No: Dr..DMXII
Power Input: DC 9v, 500mA
(An AC ~ DC adaptor included or
built-in chargeable battery)
DMX In: 3 and 5 pins male XLR connectors
DMX Out: 3 and 5 pins female XLR connectors
MIDI In: 5 pins Multi connector
Dimensions: 200 160 55 mm_ _
Weight: 1.2 kg
All rights reserved. No part of this manual may be reproduced in any form or by any
means without written permission.
Customer Support:
Elation® provides a customer support line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may also visit us on the web at
www.elationlighting.com for any comments or suggestions. For service related issue please contact
Elation . Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.®
Voice: (323) 582-3322
Fax: (323) 582-3108
E-mail: support@elationlighting.com
2
_Operation Guide
Dr. DMXII, which can be used in various lighting occasions to meet your requirements. This unit
provides ample menu options in a 20 x 4 LCD window for you. The desired menu or window can be
activated by turning the multi-selector wheel, and then pressing the multi-selector wheel in the center.
This will allow you to access the menu functions.
: If you want to forward to the next menu, please turn the multi-selector right. You may alsoNOTE
turn the wheel left to browse the previous menu option.
The power for this unit is supplied by the built-in storage battery or the DC 9v adaptor. When using
the DC 9v adaptor, the built-in battery will automatically charge at the same time. The time taken to
fully charge the battery is about 3~5 hours, which can supply power to this unit for 6~8 hours.
Switch the unit on, (the switch is on the back), and the LCD should display:
Pressing the multi-selector wheel will access the first window. The LCD window will display:
Tester hardware and
software develop by
NCW (Holdings) Ltd .
05–Apr–2003 >
You can also forward to the main window of information by using the multi-selector wheel.
If you continue to forward, there are 8 main menu options for your choice, including DMX packet
test, DMX data RX, DMX data TX, Moving light, Save Cue , Cable test, MIDI data RX,–– –– ––
System setup.
_ DMX packet test
Turn the multi-selector wheel right to select and then press the multi-selector wheelDMX packet test
center to access this menu function.
< DMX special test
DMX data––RX
DMX data––TX
_ Moving light
< DMX packet test:
1. Data format
2. Data timing
3. Data level (Volt)
>
>
>
>
>
>
>
_
< ==== Elation ====
Dr.DMX–II DMX TESTER
REV1.1
( C ) NCW 2003 >
_ ? Save Cue
Cable test
MIDI data -- RX
System setup
