SUPER SWITCHER
Programmable Effects Hub
Congratulations on your purchase of the Super Switcher, a full-featured
programmable effects hub that is capable of controlling your entire rig. The Super
Switcher is able to handle jobs as simple as an effects loop switcher or as complex
as a programmable effects loop preset designer. The Super Switcher can send tap
tempo to other pedals, includes two general purpose control outputs, and features
MIDI input and output allowing automated control over just about any MIDI device
for nearly endless possibilities. Scratch the surface of tone shaping with the Super
Switcher and achieve studio style effects programming that cannot be
accomplished with traditional pedal set ups. No more tap dancing!
WARNING: Your Super Switcher comes equipped with an Electro-Harmonix 9.6DC-200BI
power supply. The Super Switcher requires 150mA at 9VDC with a center negative plug.
Use of the wrong adapter or a plug with the wrong polarity may damage your Super
Switcher and void the warranty. Do not exceed 10.5VDC on the power plug. Power supplies
rated for less than 150mA will cause the Super Switcher to act unreliably.
FEATURES
Programmable pedal switcher
Mechanical relay switching for true bypass signal paths
8 FX loops (6 mono & 2 stereo)
16 Banks of 8 presets each
Pedalboard controller with MIDI In and Out
1 hardwired insert loop between FX loops 5 and 6
2 Instant Access Modes allowing direct control over FX loops
Stereo output boost
Onboard Tap Tempo with TAP output
Tuner output
2 general-purpose control footswitches
2
TABLE OF CONTENTS
Notes and Specifications 2
Controls and Connections 3
Ins, Outs, Sends and Returns 3
Illuminated Buttons 4
Footswitches and LEDs 4
Boost and Value Knobs 5
Preset Mode 6
Instant Access Mode 7
Control Functions 8
MIDI Control 9
MIDI Receive Message Tables 11
Setup Menu 12
Restoring Factory Settings 15
Warranty Information and Compliance 16
NOTES AND SPECIFICATIONS
Audio input impedance: 2M (buffer or boost only)
Audio output impedance for each output: 470(buffer only)
Audio output impedance for each output: 1K (boost on)
Current draw: 150mA
Maximum input signal level: +11 dBu
Bypass: Mechanical relay true bypass switching
3
CONTROLS AND CONNECTIONS
- INS, OUTS, SENDS AND RETURNS -
The Super Switcher has eight switchable effects loops, an insert loop,
mono input and stereo outputs.
Mono Input: Connect your guitar or instrument to the IN jack.
Stereo Outputs: Connect your amp(s), other effects pedals or mixer to
the OUT L and OUT R jacks. We recommend only using the L channels if
working in mono throughout your signal chain.
Mono Effects Loops 1-6: Active when illuminated buttons L1-6 are lit.
Effects loops 1-6 are mono loops arranged in series. Loops 1-6
correspond respectively to the illuminated buttons L1-6. When the
illuminated button is lit, the corresponding effects loop is active and
the signal is routed out the SEND jack and in through the RTN
(return) jack.
NOTE: If the loop is active with nothing plugged into it, the signal
will be cut off and no sound will come out of the output.
Insert Loop: Always on, hardwired loop between effects loops 5 and 6.
Series insert loop is placed between effects loops 5 and 6
When nothing is plugged into the SEND and RETURN of the insert
loop the signal bypasses the insert loop.
If an effect is placed in the insert loop, the signal will always be
routed through the effect.
Perfect for always having manual control of a certain effect.
Ideal for an always ON type of effect such as a volume pedal.
The Insert Loop is active even when master bypass is engaged.
Stereo Effects Loops 7-8: Active when buttons L7-8 are lit.
Effects loops 7 & 8 are stereo loops arranged in series. When either
of their illuminated buttons are lit (L7-8), the corresponding effects
loop is active.
Loop 7 has a single, mono SEND jack.
Loop 7 has separate left and right RTN jacks.
Loop 8 has separate left and right SEND jacks.
Loop 8 has separate left and right RTN jacks.
Loop 7 or 8 can be used in mono: connect to only their L channels.
