Electro-Voice | ND66
ND66
▪Premium small diaphragm condenser element
▪Clean, crisp, and detailed condenser sound
▪Easy mic placement with locking rotating head
▪Selectable -10dB and -20dB pads
▪Selectable 75Hz and 150Hz high pass filters
The Electro-Voice ND66 is a robust, high-performance
small diaphragm condenser instrument microphone.
The ND66 contains a self-biased small diaphragm
condenser element which is vividly responsive to the
complex dynamic nature of percussive and stringed
instruments, delivering a clean, crisp and detailed
sound.
With the ND66 exclusive locking rotating head, achieve
ideal mic placement in virtually any situation by merely
pushing a button, rotating the head into position, then
releasing the button to lock the head's position.
ND66 contains selectable -10 and -20dB pads which
provide the necessary gain reduction to prevent the
mic element from overloading when micing very loud
or high-transient sound sources.
ND66 contains selectable high pass filters which are
strategically chosen at 75Hz and 150Hz to eliminate
bothersome low frequencies from the signal path.
Technical specifications
Element Type: Self-biased Condenser
Frequency Response, Free
Field:
50Hz to 20kHz
Polar Pattern: Cardioid
Sensitivity, Open Circuit
Voltage @ 1 kHz::
10 mV / Pascal
Maximum SPL: 146 dB SPL, 0dB Pad
Self Noise: 20 dB SPL “A” weighted (0dB=20
micropascals)
Dynamic Range: 126 dB
Signal-to-Noise Ratio: 74 dB (@ 94 dB SPL)
Polarity: Pin 2 positive, reference to pin 3 with
positive pressure on diaphragm
Power Requirements: Phantom Supply Requirement: 48
VDC
Impedance: 200 ohms
Microphone Connector: 3-pin, XLR-type
Finish: Black polyurethane paint
Material: Zinc die cast
Dimensions, Length:
Diameter:
5.63 in (143 mm)
0.83 in (21 mm)
Net Weight: 6.30 oz (179 g)
Shipping Weight: 16.4 oz (465 g)
Accessories Included: (1) Gig bag, (1) stand clip, and (1)
Euro thread adapter
