Side 1/2

PL35

Dynamic Supercardioid

Snare/Tom Microphone

General Description:

Key Features:

• Voiced for open and natural tom and snare sound

• Unique body design for clean cable management

• Supercardioid polar pattern

• Excellent off-axis rejection

• Powerful Neodymium magnet structure

• Fine mesh Memraflex™ grille

Thank you for purchasing the Electro-Voice® PL35. This product is a

professional-grade supercardioid dynamic microphone designed to

deliver the power, punctuation and natural tones of toms and snare

drums in any size sound reinforcement system or recording studio.

With its frequency response designed for that special tonal area

toms and snare drums occupy, the PL35 delivers all of the “dialed-in”

tone and percussive impact detail professional drummers and sound

system engineers require. The PL35’s tight supercardioid polar pat-

tern is designed to minimize off-axis information from nearby drums

and instruments entering the capsule, and allows for a very isolated

instrument sound and higher gain before feedback.

Cable clutter and positioning in tight spaces can always be an issue

when miking toms and snares, and the PL35’s clever cable exit angle

of 37.5° relative to the body reduces the vertical space above the

drum required for the XLR connector and cable. The PL35 is supplied

with the unique DRC-1 drum rim clamp which eliminates the need

for a floor stand and boom, and allows easy-on / easy-off attach-

ment of the microphone to virtually any drum brand steel rim.

Application Notes:

As with most directional microphones, the low frequency response

of the PL35 microphone varies with the distance from the sound

source. Known as “proximity effect”, the bass response of the

microphone increases as the working distance to the microphone is

reduced. This “bass boost” is only audible when working at distances

closer than 6 inches. Therefore, working close to the microphone will

produce a more robust sound. Using this microphone at distances

greater than 6 inches provides minimal coloration from proximity

effect.

Close-up positioning of the microphone will also reduce the poten-

tial for feedback from the sound reinforcement system. Then, the

bass boost provides an increase in overall microphone output level.

The mixer gain may be proportionately reduced, resulting in a reduc-

tion of the system’s sensitivity to feedback caused by sound entering

the microphone from the loudspeakers.

Warranty:

This Electro-Voice® PL35 product is guaranteed against malfunction

due to defects in materials or workmanship for a period of three (3)

years from the date of original purchase. Please refer to the Limited

Warranty card included with your product for further warranty infor-

mation.

Technical Specifications:

Element Type: Dynamic, Neodymium Magnet

Structure

Frequency Response: 50 Hz - 16,000 Hz

Polar Pattern: Supercardioid

Sensitivity, Open Circuit

Voltage, 1 kHz:

2.2 mV/Pa (-53 dBV)

Polarity: Positive pressure on diaphragm

produces positive voltage on pin 2

relative to pin 3

Rated Impedance: 600 ohms

Microphone Connector: 3-pin, XLR-type

Finish: Textured black satin body with

Memraflex

grille

Dimensions: Length = 4.25” (108.0 mm)

Width = 1.69” (42.9 mm)

Shank = 3.20” (81.0 mm)

Accessories Included: Stand adapter with Euro-thread

insert, Drum rim clamp DRC-1, Soft

zippered gig bag

Net Weight: 8.3 oz (236 g)

Shipping Weight: 18.6 oz (527 g)

Produkspesifikasjoner

Merke:	Electro-Voice
Kategori:	Mikrofon
Modell:	PL35
Bredde:	81 mm
Dybde:	108 mm
Høyde:	42.9 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Diameter:	42.9 mm
Mikrofonretningstype:	Superkardioide
Mikrofonfrekvens:	50 - 16000 Hz
Mikrofonvekt:	236 g
Produktfarge:	Sort
Enhetsgrensesnitt:	mini XLR (3-pin)
Modell/Type:	Studiomikrofon
Mikrofonsensitivitet/mikrofonfølsomhet:	-53 dB
Inngangsimpedans mikrofon:	600 Ω
(Indre) fraktkasse, bruttovekt:	527 g
Mikrofondimensjoner (D x H):	42.9 x 108 mm
Frekvensrekkevidde:	50 - 16000 Hz
XLR utgang:	Ja
