Side 1/2

PL80c

Dynamic Supercardioid

Vocal Microphone

General Description:

Key Features:

• EQ-friendly sonic contour

• Highly detailed frequency response

• Supercardioid polar pattern

• Powerful Neodymium magnet structure

• Shock mounted capsule and low handling noise

• Fine mesh Memraflex™ grille

Thank you for purchasing the Electro-Voice® PL80c. This product is

a premium-grade supercardioid dynamic microphone designed to

elegantly capture the character of vocals in live sound applications.

The PL80c’s “EQ-friendly” sonic contour adapts well to any vocal

texture allowing vocals to sit nicely in the mix without being harsh.

The enhanced isolation provided by its supercardioid polar pattern is

an excellent defense against system feedback and cross-talk bleed

emanating from other nearby sound sources. The result is higher

gain before feedback and cleaner stage mixes. Although designed

to be a vocal microphone for music and spoken word, the PL80c will

also function well as an instrument or amplifier microphone where a

dynamic element capsule would be desired.

Application Notes:

As with most directional microphones, the low frequency response

of the PL80c microphone varies with the distance from the sound

source. Known as “proximity effect”, the bass response of the

microphone increases as the working distance to the microphone is

reduced. This “bass boost” is only audible when working at distances

closer than 6 inches. Using this microphone at distances greater

than 6 inches provides minimal coloration from proximity effect.

Proximity effect can be used to your advantage when a thin voice

is being recorded. As the vocalist decreases their working distance

to the microphone, the low frequency content is enhanced. Close-

up positioning of the microphone will also reduce the potential for

feedback from the sound reinforcement system. When close-talked,

the bass-boost provides an increase in overall microphone output

level. The mixer gain may be proportionately reduced, resulting in

a reduction of the system’s sensitivity to feedback caused by the

sound entering the microphone from the loudspeakers.

Warranty:

This Electro-Voice® PL80c product is guaranteed against malfunc-

tion due to defects in materials or workmanship for a period of three

(3) years from the date of original purchase. Please refer to the

Limited Warranty card included with your product for further warranty

information.

Technical Specifications:

Element Type: Dynamic, Neodymium Magnet

Structure

Frequency Response: 80 Hz - 16,000 Hz

Polar Pattern: Supercardioid

Sensitivity, Open Circuit

Voltage, 1 kHz:

2.2 mV/Pa (-53 dBV)

Polarity: Positive pressure on diaphragm

produces positive voltage on pin 2

relative to pin 3

Rated Impedance: 600 ohms

Microphone Connector: 3-pin, XLR-type

Finish: Textured satin handle with

Memraflex

grille

Dimensions: Length = 7.44” (189.0 mm)

Width = 2.00” (50.7 mm)

Shank = 1.01” (25.6 mm)

Accessories Included: Stand adapter with Euro-thread

insert, Soft zippered gig bag

Net Weight: 11.8 oz (333 g)

Shipping Weight: 20.7 oz (587 g)

Produkspesifikasjoner

Merke:	Electro-Voice
Kategori:	Mikrofon
Modell:	PL80c
Bredde:	50.7 mm
Dybde:	189 mm
Høyde:	50.7 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Diameter:	50.7 mm
Mikrofonretningstype:	Superkardioide
Mikrofonfrekvens:	80 - 16000 Hz
Mikrofonvekt:	333 g
Produktfarge:	Sølv
Enhetsgrensesnitt:	mini XLR (3-pin)
Modell/Type:	Karaokemikrofon
Antall medfølgende produkter:	1 stykker
Mikrofonsensitivitet/mikrofonfølsomhet:	-53 dB
Inngangsimpedans mikrofon:	600 Ω
(Indre) fraktkasse, bruttovekt:	587 g
Mikrofondimensjoner (D x H):	50.7 x 189 mm
Frekvensrekkevidde:	80 - 16000 Hz
XLR utgang:	Ja
