Side 1/2
:LUHOHVVUHFHLYHUIRUFRQWURORIHOHFWULF
KHDWLQJGHYLFHV
:$//02817('
Control of electric heating systems
The connected electric appliance is switched according to the
required temperature
Two-way radio communication at 433,92 MHz
Operating instructions
Version 11.02
BPT002
BPT002 is suitable for switching heating panels, directheaters,
radiant panels, heating mats, etc. It switches the connected de-
vice according to the information received from the transmitter.
To be installedin internal rooms. Do not locate near power lines!
TECHNICAL PARAMETERS
Power supply 230 V/ 50 Hz
Communication type two-way
Frequency 433,92 MHz
Sensitivity < - 95 dBm
Range
200 m (in free area), 25 m (in built-up area)
Output relay, max.16A/ 250 VAC
Protection IP40
Working temperature 0 to 40°C
Dimensions (LxWxD) 109 mm x 80 mm x 31mm
In case of guarantee or
post-guarantee service, send the
receiver to the manufacturer’s
address.
DECLARATION OF CONFORMITY
We, ELEKTROBOCK CZ s.r.o., herewith declare that our product BPT002 is in conformity
with the basic requirements and other respective provisions of the directive 1999/5/ES.
Issued: 1.04.2012
Pb
LEAD FREE
mit Einkland mit RoHS
MADE IN CZECH REPUBLIC
ELEKTROBOCK CZ s.r.o.
Blanenská 1763
Kuřim 664 34
Tel./fax: +420 541 230 216
www.elbock.cz
CERTIFICATE OF GUARANTEE
(guarantee period for the product amounts to 2 years)
product No.:
examined by:
date of sale:
stamp of shop:
