EMU Hardware
70681
User Manual
ENTTEC’s touring-grade USB to DMX/Art-Net interface delivers real-time lighting control for EMU software.
EMU HARDWARE (70681)
Visit the ENTTEC website for the latest version.
..
USER MANUAL
1 |
ID: 5956415
Document Updated: March 2025
Content
Safety..................................................................................................................................................................................................................... 2
Electrical safety ..................................................................................................................................................................................................................... 2
System Planning and Specification ............................................................................................................................................................................ 2
Protection from Injury During Installation ............................................................................................................................................................. 3
Installation Safety Guidelines ....................................................................................................................................................................................... 3
Hardware Feature ........................................................................................................................................................................................... 4
Physical Dimensions .......................................................................................................................................................................................................... 4
Mounting Method ................................................................................................................................................................................................................ 4
DMX Connector ...................................................................................................................................................................................................................... 5
Ethernet RJ45 .......................................................................................................................................................................................................................... 5
Footswitch and MIDI ........................................................................................................................................................................................................... 5
LED Status Indicator ........................................................................................................................................................................................................... 5
Wiring Diagram ................................................................................................................................................................................................. 5
Setup Guide ............................................................................................................................................................................................................................ 6
Functional Feature .......................................................................................................................................................................................... 7
Configuration Software ENTTEC EMU .................................................................................................................................................. 7
Device Discovery ................................................................................................................................................................................................................... 8
Configuration Options ....................................................................................................................................................................................................... 8
Connecting Footswitch or MIDI ..................................................................................................................................................................................... 8
Connecting ENTTEC Lighting Controller .................................................................................................................................................................... 9
Firmware Update ...................................................................................................................................................................................................................1
Factory Reset ...........................................................................................................................................................................................................................1
Servicing, Inspection & Maintenance.................................................................................................................................................... 2
Cleaning .................................................................................................................................................................................................................................... 2
Package Contents ............................................................................................................................................................................................ 3
Ordering Information .................................................................................................................................................................................... 3
EMU HARDWARE (70681)
Visit the ENTTEC website for the latest version.
..
USER MANUAL
2 |
ID: 5956415
Document Updated: March 2025
Safety
Ensure you are familiarized with all key information within this guide and other relevant ENTTEC
documentation before specifying, installing, or operating an ENTTEC device. If you are in any doubt
about system safety, or you plan to install ENTTEC device in a configuration that is not covered within
this guide, contact ENTTEC or your ENTTEC supplier for assistance.
ENTTEC’s return to base warranty for this product does not cover damage caused by inappropriate
use, application, or modification to the product.
Electrical safety
This product must be installed in accordance with applicable national and local electrical and
construction codes by a person familiar with the construction and operation of the product and the
hazards involved. Failure to comply with the following installation instructions may result in death
or serious injury.
Do not exceed the ratings and limitations defined in the product datasheet or this document.
Exceeding can cause damage to the device, risk of fire and electrical faults.
Ensure that no part of the installation is or can be connected to power until all connections and
work is complete.
Before applying power to your installation, ensure your installation follows the guidance within this
document. Including checking that all power distribution equipment and cables are in perfect
condition and rated for the current requirements of all connected devices and factor in overhead as
well as verifying that it is appropriately fused and voltage is compatible.
Remove power from your installation immediately if accessories power cables or connectors is in
any way damaged, defective, shows signs of overheating or are wet.
Provide a means of locking out power to your installation for system servicing, cleaning and
maintenance. Remove power from this product when it is not in use.
Ensure your installation is protected from short circuits and overcurrent. Loose wires around this
device whilst in operation, this could result in short circuiting.
Do not over stretch cabling to the device’s connectors and ensure that cabling does not exert force
on the PCB.
Do not ‘hot swap’ or ‘hot plug’ power to the device or its accessories.
Do not connect any of this device’s V- (GND) connectors to earth.
Do not connect this device to a dimmer pack or mains electricity.
System Planning and Specification
To contribute to an optimal operating temperature, where possible keep this device out of direct
sunlight.
Any twisted pair, 120ohm, shielded EIA-485 cable is suitable to transmit DMX512 data. The DMX cable
should be suitable for EIA-485 (RS-485) with one or more low capacitance twisted pairs, with overall
braid and foil shielding. Conductors should be 24 AWG (7/0.2) or larger for mechanical strength and
to minimize volt drop on long lines.
A maximum of 32 devices should be used on a DMX line before re-generating the signal using a DMX
buffer/ repeater / splitter.
Always terminate DMX chains using a 120Ohm resistor to stop signal degradation or data bounce-
back.
The maximum recommended DMX cable run is 300m (984ft). ENTTEC advises against running data
cabling close to sources of electromagnetic interference (EMF) i.e., mains power cabling / air
conditioning units.
This device has an IP20 rating and is not designed to be exposed to moisture or condensing humidity.
