6 Securely close the black ink tank cap.
7 Repeat the previous steps for the other colors.
8 Close the ink tank cover.
9 Raise the control panel, then press the power button to
turn on the product. The powerlightashes.
Note:Ifanerrorcodeappears,turnotheproductandcheck
that no protective material has been left inside the product.
10 ET-3930/ET-3940/ET-3950 Series: Select your language.
ET-4950 Series: Select your language, country, date, and
time settings.
Note: You can change these settings later using the product’s
control panel. For more information, see the online User’s Guide.
11 When an Epson Smart Panel setup message appears on
the LCD screen, select the option to continue setup from
the control panel.
12 When the message to see the Start Here sheet appears
on the LCD screen, press and hold the help button for
5 seconds.
13 Follow the on-screen instructions to start ink charging. Ink
charging takes about 11 minutes.
Note: When the powerlightstopsashing,inkchargingis
complete. Once initial setup of the printer is complete, you can
topotheinktankswithanyremainingink.Aftersomeinkis
used for charging, the rest is available for printing. See the online
User’s Guide for instructions.
Caution:Donotunplugorturnotheproduct,orraisethe
scanner unit while the product is charging or you’ll waste ink.
14 ET-3930/ET-3940/ET-3950 Series: Press the OK button
to proceed with initial setup.
ET-4950 Series: Select To adjustment to proceed with
initial setup.
IMPORTANT: Before using this product, make sure you read
these instructions and the safety instructions in the online
User’sGuide.
Important Safety Instructions (ET-4950 Series): When using telephone
equipment, you should always follow basic safety precautions to reduce
the risk of fire, electric shock, and personal injury, including the following:
• Do not use the Epson
®
product near water.
• Alwayskeepthisguidehandy.
• Avoidusingatelephoneduringanelectricalstorm.Theremaybea
remote risk of electric shock from lightning.
• Do not use a telephone to report a gas leak in the vicinity of the leak.
Caution:Toreducetheriskoffire,useonlyaNo.26AWGorlarger
telecommunication line cord.
The illustrations show the ET-4950, but the steps are the same for
theothermodels,unlessotherwisespecied.
1
Unpack
ET-3930/ET-3940/ET-3950 Series
ET-4950 Series
Note: Do not open the ink bottles until you are ready to fill the ink
tanks. The ink bottles are vacuum packed to maintain reliability.
1 Remove all protective materials from the product.
Caution:Donottouchtheatwhitecableortheinktubesand
their translucent cover.
2 Connect the power cord to
the back of the product and
to an electrical outlet.
Caution: Do not connect to
your computer yet.
2
Choose a setup method
The Epson Smart Panel
®
app can help you set up your printer
through an interactive, step-by-step process using your
smartphoneortablet.Aftersetup,you’llbeabletoprintand
scan directly from the app.
Note: If you want to print and scan from your computer, you need to
install the product’s software. See the “Install software” section on the
back of this sheet for instructions.
If you do not want to
use a mobile device for
setup, skip to the “Fill ink
tanks” section.
To use your mobile device
for setup (recommended),
continue to step 1.
OR
1 Download the Epson Smart Panel app
from your device’s app store. Do not
launch the app yet.
2 Press the power button until it lights up to turn on the
product.
Note: Do not connect your product to your computer yet.
3 Launch the app and follow its instructions to set up your
product. If necessary, tap the + icon on the top right
corner of the app’s home screen and select the option to
set up a new product.
For information on solving problems or reaching Epson
support, see the back of this sheet.
3
Fill ink tanks
Warning: Keep the ink bottles out of the reach of children and do not
drink the ink.
Caution: This product requires careful handling of ink. If ink spills,
wipeitoimmediatelywithadamptoweltoavoidpermanentstains.
Ifinkgetsonyourclothesorbelongings,itmaynotcomeo.
Note:
• Epson cannot guarantee the quality or reliability of third-party ink.
• Use the ink bottles included with the printer to set up the product.
Part of the ink will be used to charge the printhead. These bottles
may print fewer pages compared with replacement ink bottles.
• Epson strongly recommends the use of genuine ink to ensure
optimal print quality and performance.
1 Open the ink tank cover, then open the cap for the black
(BK) ink tank.
Note: Refer to the color-coded sticker to identify the color of
each tank.
2 Unpack the black (BK) ink bottle. Hold the ink bottle
upright and slowly turn the bottle cap to remove it.
Caution: Do not shake or squeeze the ink bottle. Do not touch
the top of the ink bottle after its cap is removed.
3 Inserttheinkbottleintothellingport.
Note: Do not force the bottle into position; each bottle is keyed
for each color.
4 Waitfortheinktollthetank.
Do not squeeze the bottle or
allow it to contact any other
surface.
Note:Inkowsintothetankand
stops automatically when the ink
tankislledtotheupperline.Ifink
doesnotowfromthebottle,liftand
reinsert the bottle.
5 When the ink tank is full, remove the ink bottle and
securely close it with the bottle cap. If any ink remains in
the bottle, store it for later use.
Note: Do not leave the ink bottle inserted; otherwise the bottle
may be damaged or ink may leak.
Start Here
ET-3930/ET-3940/ET-3950/ET-4950 Series
5
Connect fax line
(ET-4950 Series)
1 Connect a phone cord to a telephone wall jack and to the
LINE port on your product. See the online User’s Guide
for more information.
2 Select Proceed on the LCD screen to set up the fax, or
select Set Up Later to set it up later.
6
Install software
Note:
• AnInternetconnectionisrequiredtoobtaintheproductsoftware.
• To print from a Chromebook™, go to
http://epson.com/support/chromebookprint (U.S.) or
http://epson.ca/support/chromebookprint (Canada) for
instructions.
1 Make sure the product is NOT CONNECTED to your
computer.
Windows
®
: If you see a Found New Hardware screen, click
Cancel and disconnect the USB cable.
2 Download and run your product’s software package. For
the latest software, visit: http://epson.com/support (U.S.)
or http://epson.ca/support (Canada) and search for your
product.
3 Follow the instructions on the computer screen to run the
setup program.
4 When you see the Select Your Connection screen, select
one of the following and follow the on-screen instructions:
•
Wireless connection
In most cases, the software installer automatically
attempts to set up your wireless connection. If setup
is unsuccessful, you may need to enter your network
name (SSID) and password.
•
Direct USB connection
Make sure you have a USB cable (not included).
•
Wired network connection
Make sure you have an Ethernet cable (not included).
Mobile printing
• Turn your mobile device into an intuitive, easy-to-use
printing and scanning control center with Epson Smart
Panel. Download the app from your mobile device’s app
store.
• PrintdirectlyfromyourAndroid™(v4.4orlater)device*.
Simply connect your printer and device to the same network
and tap the menu icon to select the print option.
• Print from wherever you are, next to your printer or
remotely, with Epson Connect™. Learn more at
http://epson.com/connect (U.S.) or
http://epson.ca/connect (Canada).
*MayrequiretheEpsonPrintEnablerorMopria
®
Print Service app from
GooglePlay™.
EPSON and Epson Smart Panel are registered trademarks and Epson Connect is a trademark of
Seiko Epson Corporation.
DesignedforExcellenceisatrademarkofEpsonAmerica,Inc.
MacisatrademarkofAppleInc.,registeredintheU.S.andothercountries.
Android,Chromebook,andGooglePlayaretrademarksofGoogleLLC.
TheMopriawordmarkisaregisteredand/orunregisteredtrademarkofMopriaAlliance,Inc.inthe
United States and other countries. Unauthorized use is strictly prohibited.
Windows is a trademark of the Microsoft group of companies.
GeneralNotice:Otherproductnamesusedhereinareforidenticationpurposesonlyandmaybe
trademarks of their respective owners. Epson disclaims any and all rights in those marks.
This information is subject to change without notice.
©2024EpsonAmerica,Inc.,9/24
Printed in XXXXXX CPD-64026
15 Follow the on-screen instructions to adjust the print
quality of your product.
Note:
• You need to load paper before you can adjust the print quality.
See “Load paper” on this sheet for details.
• Select Adjust Later if you want to adjust the print quality later.
For more information, see the online User’sGuide.
Caution:Aftersetup,periodicallyinspecttheinklevelstoensurethey
do not fall below the lowest lines on the tanks. Prolonged use when
ink is below the lowest line could damage the product. See the online
User’s Guideforrellinginstructions.
4
Load paper
See the online User’s Guide for information about loading
capacity,availablepapertypesandsizes,usingtheADF
(ET-3940/ET-3950/ET-4950 Series), and loading envelopes.
1 Make sure the product is not charging ink, and then open
the front of the paper cassette and pull out the paper
cassette.
2 Slide the edge guides all the way out.
3 Insert paper with the glossy or printable side down.
Note: Make sure the paper is loaded against the front edge
guide and not sticking out from the end of the cassette.
4 Slide the side edge guides against the paper, but not
too tightly.
5 Keepthecassetteatasyouinsertitalltheway.
6 Close the front of the paper cassette.
7 Select the paper settings on the product’s control panel.
Any problems?
Network setup was unsuccessful.
• Make sure you select the right network name (SSID).
• Restartyourrouter(turnitoandthenon),thentryto
connect to it again.
• Ifyouseearewallalertmessage,clickUnblock or Allow
to let setup continue.
• If your network has security enabled, make sure you enter
yournetworkpassword(WEPkeyorWPApassphrase)
correctly. Be sure to enter your password in the correct
case.
• Print a network connection report to identify network
problems and solutions. See your online User’sGuide for
instructions.
There are lines or incorrect colors in my printouts.
Run a nozzle check to see if there are any gaps in the printout.
Then clean the printhead, if necessary. See the online User’s
Guide for more information.
The product’s screen is dark.
Make sure your product is turned on, and press any button
(ET-3930/ET-3940/ET-3950 Series) or touch the screen
(ET-4950 Series) to wake it from sleep mode.
Setup is unable to find my product after connecting it
with a USB cable.
Make sure your product is on and the USB cable is securely
connected.
Any questions?
User’s Guide
Windows:ClicktheicononyourdesktoporAppsscreento
access the online User’sGuide.
Mac:ClicktheiconinApplications/EpsonSoftware/Guideto
access the online User’sGuide.
Ifyoudon’thaveaUser’sGuideicon,gototheEpsonwebsite,
as described in “Technical support.”
Technical support
Visit http://epson.com/support (U.S.) or
http://epson.ca/support (Canada) and search
for your product to download drivers, view videos
andmanuals,getFAQs,orcontactEpson.
Call (562) 276-4382 (U.S.) or (905) 709-3839 (Canada), 7 a.m.
to4p.m.,PacicTime,MondaythroughFriday.Daysand
hours of support are subject to change without notice. Toll or
long distance charges may apply.
Recycling
Epsonoersarecyclingprogramforend-of-lifehardware
and ink bottles. Please go to http://epson.com/recycle (U.S.)
or http://epson.ca/recycle (Canada) for information on how to
return your products for proper disposal.
Need paper and ink?
Ensure brilliant results with Epson specialty and plain
papers,engineeredspecicallyforEpsonprinters.Find
EpsonpapersandEpsonGenuineInkathttp://epson.com
(U.S. sales) or http://epson.ca (Canadian sales) and at Epson
authorizedresellers.Call800-GO-EPSON(800-463-7766).
ET-3930/ET-3940/ET-3950/ET-4950 Series replacement inks
Black Cyan Magenta Yellow
502120 502220 502320 502420
Produkspesifikasjoner
| Merke: | Epson |
| Kategori: | Printer |
| Modell: | EcoTank ET-3943 |
Trenger du hjelp?
Hvis du trenger hjelp med Epson EcoTank ET-3943 still et spørsmål nedenfor, og andre brukere vil svare deg
Printer Epson Manualer
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
6 Oktober 2025
Printer Manualer
- Microboards
- Mutoh
- Kodak
- Datamax-O'neil
- Phoenix Contact
- Star
- Brother
- Pantum
- Evolis
- IDP
- Samsung
- HP
- Tally Dascom
- GoDEX
- Unitech
Nyeste Printer Manualer
6 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
5 Oktober 2025
