Full-Motion TV Wall Mount
INSTRUCTION
MANUAL
Rev00(A)
ERMMM7-01B
(877) 419-7832 support@ergoav.com
www.ergoav.com
WWW.
508mm (20″)
02
04
04
01
01
05
02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
IMPORTANT SAFETY INFORMATION
• Avoid the risk of personal injury or property damage! Tighten the lag screws only until
they are pulled firmly against the wall plate (DO NOT overtighten). Do not use a drill;
only use a socket wrench.
Do not use wall anchors for this mounting option. Wall anchors are used for solid
concrete, concrete block, and brick installations only.
• Minimum wood stud size: 1 1/2″ W x 3 1/2″ D (38 x 89mm)
• Wood stud spacing: 8″ to 16″ (center to center)
• Note: If the wood studs are more than 16″ apart, or if the studs are not in the desired
mounting location, you can secure (2) wood boards (or extension brackets) to the wall
studs, then install the TV mount on the boards. Minimum wood board dimensions:
1 1/2″ T x 3 1/2″ W x >18″ L (38 x 89 x >457mm)
• Avoid the risk of personal injury or property damage! Tighten the lag screws only until
they are pulled firmly against the wall plate (DO NOT overtighten). Do not use a drill;
only use a socket wrench.
• Mount the arm assembly / wall plate directly on the concrete surface.
• Minimum solid concrete thickness: 8″ (203mm)
• Minimum concrete block size: 8 x 8 x 16″ (203 x 203 x 406mm)
• Never drill into the mortar between blocks or bricks.
NOTE
CAUTION
WARNING
Note for Wood Stud Installation (Page 10-11)
Note for Solid Concrete, Concrete Block, or Brick Wall Installation
(Page 11-12)
• Please carefully read all instructions before attempting installation. If you do not under-
stand the instructions or if you have any questions or concerns, please call technical
support or email customer service.
• Before starting assembly, verify that all parts are included and undamaged. Do not use
damaged or defective parts. lf you require replacement parts, please call technical
support or email customer service.
• Not all hardware included in this package will be used.
• Avoid the risk of personal injury or property damage!
• Do not use this product for any purpose that is NOT explicitly specified in this manual.
Do not exceed the maximum weight capacity. We are not liable for damage or injury
caused by incorrect assembly, improper mounting, or inappropriate use.
• This product is designed for installation on wood stud, solid concrete, concrete block,
and brick walls. DO NOT install on drywall alone.
• The wall must be capable of supporting four times the weight of the TV and mount com-
bined.
• This product contains small parts that may pose a choking hazard.
