Side 1/8

INTRODUCTION









NOTES

Do not discard. Give this guide to the owner/operator after installation.

• 



• 







• 



• 



• 



• 





• 



• 

PENTAIR® EVERPURE 

QC7I FC COLDRINK® 4FC INSURICE® 4FC-S

QC7I FC-S COLDRINK 7FC INSURICE 7FC-S

QC7I FC5

QC7I FC5-S

OPERATING SPECIFICATIONS









 



FC SERIES WATER FILTRATION SYSTEMS

INSTALLATION, OPERATION & MAINTENANCE GUIDE

MOUNTING AND CONNECTION CONSIDERATIONS





• 

• 

• 

• 



• 



19.3 inches

(49.02 cm)

29.6 inches

(74.18 cm)

Coldrink®4 7FC

Insurice® Quad PF 7FC

Inlet/Outlet: 3/4" FNPT

Operating weight: 55 lbs (25 kgs)

Coldrink4 4FC

Insurice Quad PF 4FC

Inlet/Outlet: 3/4" FNPT

Operating weight: 43 lbs (20 kgs)

Coldrink3 7FC

Insurice Triple PF 7FC-S

Inlet/Outlet: 3/4" FNPT

Operating weight: 45 lbs (21 kgs)

QC7I PF Twin 7FC | QC7I PF Twin 7FC-S

QC7I PF Twin 7FC5 | QC7I PF Twin 7FC5-S

Inlet/Outlet: 3/4" FNPT

Operating weight: 35 lbs (16 kgs)

QC7I Twin 7FC | QC7I Twin 7FC-S

QC7I Twin 7FC5 | QC7I Twin 7FC5-S

Inlet/Outlet: 3/4" FNPT

Operating weight: 19 lbs (9 kgs)

QC7I Triple 4FC

QC7I Triple 4FC5

Inlet/Outlet: 3/4" FNPT

Operating weight: 23 lbs (10.5 kgs)

QC7I PF Twin 4FC

QC7I PF Twin 4FC-S

Inlet/Outlet: 3/4" FNPT

Operating weight: 24 lbs (10.9 kgs)

QC7I Twin 4FC | QC7I Twin 4FC-S

QC7I Twin 4FC5 | QC7I Twin 4FC5-S

Inlet/Outlet: 3/4" FNPT

Operating weight: 17 lbs (7.7 kgs)

QC7I PF Single 7FC

QC7I PF Single 7FC-S

Inlet 3/4" / Outlet: 3/8" FNPT

Operating weight: 22 lbs (10 kgs)

QC7I Single 7FC | QC7I Single 7FC-S

QC7I Single 7FC5 | QC7I Single 7FC5-S

Inlet/Outlet: 3/8" FNPT

Operating weight: 9 lbs (4 kgs)

QC7I Single 4FC | QC7I Single 4FC-S

QC7I Single 4FC5 | QC7I Single 4FC5-S

Inlet/Outlet: 3/8" FNPT

Operating weight: 8 lbs (3.7 kgs)















































PENTAIR® EVERPURE®

INSTALLATION PRECAUTIONS

• Feed water supply pressure must not exceed 125 psi (non-shock).

When pressure exceeds 85 psi, a pressure reducing valve is

recommended.

• If water hammer is evident, install a water hammer arrestor

before the Pentair® Everpure® system.

• Do not use liquid pipe compounds for tting connections.

Use two (2) or three (3) wraps of PTFE thread sealant tape.

• Do not over-tighten tting connections. Always back-up valves

and ttings with a wrench to avoid excessive stress on system

components.

INSTALLATION PROCEDURE

IMPORTANT: Conrm with the manager, and or owner/operator

that equipment to be fed by the ltration system is turned off or

not in use. The water supply to equipment will be shut off during

installation.

NOTE: For installations in Australia and New Zealand product must

be installed with a backow prevention device in accordance with

AS/NZS 3500 and AS/NZS 2845.1.

1. Locate the feed water supply shut-off valve and turn off.

NOTE: If not available, we recommend the installation of a

full-ow ball valve on the supply line to be connected to the

Pentair Everpure system. This will allow the system to be

serviced without shutting off the main water supply. (It will not

be necessary to use this valve when replacing lters.)

2. Use the predrilled mounting holes in the manifold bracket as a

guide to mark and drill anchor holes. Mount the system securely

using fasteners suitable to support the operating weight of the

system.

3. Connect the feed water supply line from the full-ow ball valve

to the inlet connection of the Everpure system.

Use a minimum 3/8-inch water line for the “single”

models. Use a minimum 1/2-inch water line for

“twin”, “triple” and “quad” models.

4. Connect tubing (supplied) to ush valve located at

the bottom of the system outlet tting and route

to drain.

NOTE: Some municipal plumbing codes and good sanitary

practices require an air gap at the drain termination point.

5. If the model includes a pre-lter, install the pre-lter. Check

to be sure the O-ring on the pre-lter housing is suciently

lubricated. If needed, use a good grade of silicone lubricant.

Insert the pre-lter into the sump and position the cartridge on

guide seat in the bottom of the sump. Then thread the sump into

the head by hand. Hand-tighten to snug the sump onto the head.

6. Install the primary lter cartridge(s) into the lter head(s)

following the directions below or as shown in the Cartridge

Change Instructions (p.6).

A. Hold lter head rmly. Align cartridge lug with label – push up

and insert the new cartridge rmly into the head.

B. Turn cartridge to right (1/4 turn) until rotation stops.

7. Select the appropriate size supply line for the equipment being

served and connect it to the outlet port of the system.

8. Connect the outlet supply line to equipment served as required.

9. With the system inlet shut-off valve in the closed/off position,

slowly open the feed water supply full-ow ball valve. Check for

leaks from the plumbing leading to the system inlet connection.

10. Ensure the ush valve line is securely attached at the drain, or

hold the tubing over a bucket or drain.

11. Slowly open the system inlet valve and allow water to ow

through the ush valve for ve (5) minutes to purge air and ush

the system media.

12. After ushing, close the ush valve and check for leaks.

13. If no leaks, the installation is complete.

14. Inform the manager and or owner/operator that the equipment

serviced can now be turned on and checked for normal

operation.

Leave this installation, operation, and maintenance manual

with the establishment for future reference.

WARNING: FOR CORRECT OPERATION OF THIS APPLIANCE IT IS

ESSENTIAL TO OBSERVE THE MANUFACTURER’S INSTRUCTIONS.

Air Gap

PENTAIR® EVERPURE® FC SERIES WATER FILTRATION SYSTEMS INSTALLATION, OPERATION & MAINTENANCE GUIDE • 3
