Side 1/1
SMT-8M-A-NO-24V-E-...
Proximity sensor
Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Deutschland
+49 711 347-0
www.festo.com
Operating instructions
8159947
2021-06a
[8159949]
Translation of the original instructions
© 2021 all rights reserved to Festo SE & Co. KG
1
About this document
1.1 Applicable documents
All available documents for the product
è
www.festo.com/sp.
2 Safety
2.1 Safety instructions
–Before working on the electrical system: switch off the power supply.
WARNING
Risk of injury due to electric shock.
• For the electric power supply, use only PELV circuits that ensure a reliable
electric disconnection from the mains network.
•
Observe IEC 60204-1/EN 60204-1.
2.2 Intended use
This product is intended for sensing the position of magnets (e.g. the piston
position) in products from Festo. The device is intended for use in an industrial
environment.
2.3 Area of application and approval
In combination with the UL inspection mark on the product, the information in this
section must also be observed in order to comply with the certification conditions
of Underwriters Laboratories Inc. (UL) for USA and Canada.
UL approval information
Product category code NRKH, NRKH7
File number E232949
Considered standards UL 60947-1, CAN/CSA C22.2 No. 60947-1
UL 60947-5-2, CAN/CSA C22.2 No. 60947-5-2
UL mark
Industrial Control Equipment
2MD1
Tab. 1:
UL approval information
Only for connection to a NEC/CEC Class 2 supply.
The device shall be supplied from an isolating transformer having a secondary
listed fuse rated 1 A.
3 Mounting instructions
Fig.1
4 Electrical connection
SMT-8M-A-NO-24V-E-…-
M8/M8D M12 OE
Tab. 2
5
Technical data
SMT-8M-A-NO-…
Operating voltage range [V AC/DC] 5 … 30
Max. output current [mA] 100
Max. switching capacity [W] 2.8
Ambient temperature [°C] –40 … +85
Ambient temperature with
flexible cable installation
[°C] –20 … +85
Degree of protection IP65, IP68, IP69k
Tab. 3
