1H
Your model
Your remote control
Selecting a wash program
Loading and detergent
Signal indicator
A single flash
indicates a
successful
signal to the
dishwasher.
Multiple flashes
indicate that
the dishwasher
cannot read
the signal. The
remote control
may be out of
range.
Mounting your
remote
Your remote control
comes supplied with a
detachable mounting
bracket and self
adhesive strip. You can
choose to affix this
bracket on a nearby
surface, which should be
out of direct sunlight
and away from excessive
heat and steam. Do not
apply on wallpaper.
Slide off remote, then
press bracket firmly to
surface for 30 seconds.
Wait 1 hour before
refitting remote.
Press
remote & bracket
to clean, dry surface
for 10 seconds
10 seconds
30 seconds
Peel red liner off,
press adhesive to bracket
Doubles remote shown
Peel black
liner off
‘Battery low’ indicator
When this
flashes, the
battery needs to
be replaced. Use
a CR2032 battery,
ensuring the
+ symbol faces up.
Double models only
(operates lower drawer)
Control button(s)
See section ‘Operating instructions’
for information.
Important!
To prevent unauthorized use, keep the remote control out of reach of children.
Discard scraps
Scrape large food particles off
(e.g. bones, fruit stones) and
remove any foreign objects
(e.g. toothpicks, strings, paper).
Add detergent and check rinse
aid
Fill the detergent dispenser (a) with
powdered detergent and close the
dispenser door.
Important!
Do not place liquid detergent or tablets in
the detergent dispenser.
If the indicator on its plug (c) glows
bright red, refill the rinse aid
dispenser (b) with liquid rinse aid.
Make sure you then refit the rinse
aid plug back into its original
position.
If using a tablet, place it in the
cutlery basket (d) or at the bottom
of the drawer.
1 4
4
21
3
2
3
Load dishes carefully
To help with wash performance,
arrange dishes so they are
evenly spaced and not nesting.
Check spray arm(s)
Ensure there are no items
blocking the spray arm(s) from
rotating.
DD60DI7
DD24D(H)(T)I7
DD60S(T)I7
DD24S(H)(T)I7
DD90STI2
DD36STI2
Operating instructions
a
b
d
c
You can operate your dishwasher in two ways:
EITHER
by using the button
on the drawer control panel
OR
by using the remote
control button
Note: each drawer in
double models has its own
controls and can run
independently of the
other drawer.
Start/resume wash
1
Press .
2
Close the drawer. The wash will start.
Pause wash
You can only pause the wash with the
remote. See opposite.
Cancel wash
1
Pause the wash with the remote.
2
Open the drawer, then press and
hold until you hear a
quick double beep.
Any water in the drawer will automatically
drain when you close it.
Set Delay start
To delay the start of a wash by 1 to 12
hours:
Press and hold . Count the beeps
as the dishwasher emits them (each
represents 1 more hour of delay) and
release the button when you have
reached the desired delay time.
The indicator of the selected wash
program will flash to show that Delay
start has been set.
The wash will start once the delay
time is over, provided the drawer is
closed.
Cancel Delay start
Press and hold
until you hear a quick
double beep and the indicator of the
selected wash program goes out.
Start/resume wash
1
Close the drawer.
2
Press . The wash will start.
Pause wash
Press
.
After pausing a wash, wait for 3 beeps
before opening the drawer. Forcing it open
in mid-cycle may cause damage or injury.
Cancel wash
Press and hold until you hear a quick
double beep.
Any water in the drawer will automatically
drain.
Set Delay start
You can only set Delay start on the drawer
control panel. See opposite.
Cancel Delay start
Press and hold until you hear a quick
double beep.
Keep this document handy for easy reference.
For detailed information on the features of your dishwasher, see your ‘User guide’.
Before using your dishwasher, make sure you read the full ‘User guide’, with special attention to the ‘Safety and warnings’ section.
For contact information or if you require service, assistance or replacement parts, see the end of this document or your ‘Service & warranty’ booklet.
NZ AU US CA
QUICK START GUIDE
DishDrawer
TM
dishwasher (Integrated)
ECO indicator
The indicator will
glow red when an
Eco program has
been selected.
Wash
program
selector
Press to
scroll
through the
wash
programs.
RINSE
Prevents
odors
and soils
drying on
dishes.
Wash program indicators
These show which program is selected.
continued over
STANDARD PROGRAMS - designed to your dishesclean and dry
ECO PROGRAMS - designed to your dishes energy-efficientlyclean
HEAVY
Heavily soiled
pots, pans and
dishes.
HEAVY ECO
Heavily soiled
everyday
dishes.
FAST
Lightly soiled
dishes.
FAST ECO
Lightly soiled,
non-greasy
dishes.
DELICATE
Lightly soiled
and heat
sensitive
crockery.
DELICATE
ECO
Lightly soiled,
non-greasy
and heat
sensitive
crockery.
NORMAL
Dishes that are
quite heavily
soiled or food
soils that have
been left to dry
overnight
NORMAL
ECO
Normal soiled
dishes for
optimum
water and
energy usage.
The Energy
Guide is based
on this cycle.
After the wash
Dos and don’ts of loading
Preference options
Closed Drawer autolock using the remote control
The dishwasher will beep six times to indicate the end of the wash program.
You may notice the following noises at the end of the wash. These are all part of normal operation:
In double models, both drawers may be draining simultaneously.
The drying fan may continue to run after a wash program has finished for a set time. The fan assists with drying and uses
negligible amounts of energy.
For best drying results, we recommend unloading the dishes once they have cooled.
You can change the setting of these options to suit your preferences or circumstances. We recommend selecting the most suitable
settings before you start using your dishwasher.
The Closed Drawer autolock feature will lock the dishwasher when the drawer is closed. To enable this feature - with the drawer closed
(and no wash program or delay start is active), press and hold
on the remote for 6 seconds until you hear a sequence of 4 beeps
together. Ignore any beeps prior to the 6 seconds. The drawer is now locked. To unlock, press once. You will hear a sequence of 4 beeps
together. The drawer is now unlocked.
On double products, the drawers must be locked independently.
If the power to the dishwasher is disconnected, the drawer will remain locked.
Note: this feature is highly recommended if the dishwasher is to be used in motor homes.
How to change the setting of an option
1
CHECK & OPEN
Check that there is no wash underway, then open the drawer.
2
ENTER MENU & SCROLL TO OPTION
To enter the menu: press first with one finger, then with another finger, hold both until one long beep sounds, then
release.
You are now in the Rinse aid option of the preference options menu.
If you want to change the Rinse aid setting, go to step 3 now.
If you want to change the setting of another option, you will need to scroll to that option first.
To scroll to the next option: press . To know which option you’re in, keep track of the sequence of options using the table below.
When you have scrolled to the end of the sequence, it will start again with Rinse aid (after the lower tone).
3
CHANGE SETTING
Press to change the setting within an option. For example, to change the Rinse aid setting from 4 (factory default) to 2, you need
to press 3 times.
4
SAVE SETTING & QUIT MENU
Press and hold until a beep sounds and the control panel reverts to showing the wash program currently selected.
*This option is disabled on models without water softener. It appears in the sequence of options but cannot be adjusted.
A neatly arranged load with evenly
spaced dishes helps wash performance.
Sharp or pointed items must be placed
horizontally or with sharp edges/points
facing down to avoid risk of injury.
Overcrowding reduces wash
performance.
Protruding items will stop the
internal lid of the drawer from
sealing properly, which could result
in a service call.
Ensure there is enough space between
plates. Mix spoons, knives and forks
within the cutlery basket to prevent
them from nesting.
If plates and cutlery are nesting,
they are less likely to be cleaned
well.
Ensure that water reaches all items on
the adjustable racks.
Dishware is blocking water from
reaching items on the adjustable
racks.
Option Rinse aid Water softener* Beeps at end of wash
What does it do?
Regulates the amount of rinse aid
dispensed. Reduce this setting if there is
excess foam after a wash. Increase this
setting if dishes are wet or streaky after
a wash.
Refer to the ‘Water softener’
section of the ‘User guide’ for
details.
Your dishwasher is factory-set to beep
six times at the end of a wash. You can
turn this setting off.
Option Rinse aid Water softener* Beeps at end of wash
Possible settings
1 to 5 0 to 5 On/Off
Example
4 indicators lit = setting is 4
3 indicators lit = setting is 3
On
Off
For more info
For detailed information on the
features of your dishwasher
For warranty information
If you…
have any questions or comments
need a Fisher & Paykel authorized
technician to service your product
need replacement parts or accessories
want to register your product
see your ‘User guide’
see your ‘Service and warranty’ booklet
see your ‘Service and warranty’ booklet or contact us
NZ toll-free, 24/7 0800 372 273 www.fisherpaykel.co.nz
AU toll-free, 24/7 1300 650 590 www.fisherpaykel.com.au
USA
toll-free, 24/7 1 888 936 7872 www.fisherpaykel.com
CA
toll-free, 24/7 1 888 936 7872 www.fisherpaykel.ca
590194C 09.12
Produkspesifikasjoner
| Merke: | Fisher Paykel |
| Kategori: | Oppvaskmaskin |
| Modell: | DD60SI7 |
Trenger du hjelp?
Hvis du trenger hjelp med Fisher Paykel DD60SI7 still et spørsmål nedenfor, og andre brukere vil svare deg
Oppvaskmaskin Fisher Paykel Manualer
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
6 Desember 2024
Oppvaskmaskin Manualer
- Oppvaskmaskin Teka
- Oppvaskmaskin Maytag
- Oppvaskmaskin Miele
- Oppvaskmaskin Whirlpool
- Oppvaskmaskin Etna
- Oppvaskmaskin Haier
- Oppvaskmaskin KitchenAid
- Oppvaskmaskin Pelgrim
- Oppvaskmaskin Royal Catering
- Oppvaskmaskin LG
- Oppvaskmaskin Bosch
- Oppvaskmaskin Jocel
- Oppvaskmaskin BEKO
- Oppvaskmaskin Exquisit
- Oppvaskmaskin Grundig
- Oppvaskmaskin Hisense
- Oppvaskmaskin Sharp
- Oppvaskmaskin Electrolux
- Oppvaskmaskin Café
- Oppvaskmaskin Balay
- Oppvaskmaskin Siemens
- Oppvaskmaskin Koldfront
- Oppvaskmaskin Arcelik
- Oppvaskmaskin Smeg
- Oppvaskmaskin Hoover
- Oppvaskmaskin Saba
- Oppvaskmaskin Hotpoint
- Oppvaskmaskin Nabo
- Oppvaskmaskin Amica
- Oppvaskmaskin IKEA
- Oppvaskmaskin Ignis
- Oppvaskmaskin AEG
- Oppvaskmaskin Rosieres
- Oppvaskmaskin Artusi
- Oppvaskmaskin Cecotec
- Oppvaskmaskin Samsung
- Oppvaskmaskin Neff
- Oppvaskmaskin Delonghi
- Oppvaskmaskin Comfee
- Oppvaskmaskin Imarflex
- Oppvaskmaskin Bomann
- Oppvaskmaskin Edgestar
- Oppvaskmaskin Kogan
- Oppvaskmaskin Caple
- Oppvaskmaskin Midea
- Oppvaskmaskin Franke
- Oppvaskmaskin Sauber
- Oppvaskmaskin Candy
- Oppvaskmaskin CDA
- Oppvaskmaskin Kuppersbusch
- Oppvaskmaskin Gorenje
- Oppvaskmaskin Summit
- Oppvaskmaskin Brandt
- Oppvaskmaskin Gram
- Oppvaskmaskin Master Kitchen
- Oppvaskmaskin Monogram
- Oppvaskmaskin Vox
- Oppvaskmaskin Westinghouse
- Oppvaskmaskin Medion
- Oppvaskmaskin Kluge
- Oppvaskmaskin Privileg
- Oppvaskmaskin MPM
- Oppvaskmaskin Cosmo
- Oppvaskmaskin Euro Appliances
- Oppvaskmaskin Bauknecht
- Oppvaskmaskin Frigidaire
- Oppvaskmaskin Defy
- Oppvaskmaskin Euromaid
- Oppvaskmaskin GE
- Oppvaskmaskin Omega
- Oppvaskmaskin Fulgor Milano
- Oppvaskmaskin Hyundai
- Oppvaskmaskin Infiniton
- Oppvaskmaskin Indesit
- Oppvaskmaskin Asko
- Oppvaskmaskin Blaupunkt
- Oppvaskmaskin Cylinda
- Oppvaskmaskin AYA
- Oppvaskmaskin Fisher And Paykel
- Oppvaskmaskin Elba
- Oppvaskmaskin Philco
- Oppvaskmaskin Jenn-Air
- Oppvaskmaskin Wisberg
- Oppvaskmaskin ECG
- Oppvaskmaskin Klarstein
- Oppvaskmaskin ATAG
- Oppvaskmaskin Freggia
- Oppvaskmaskin V-Zug
- Oppvaskmaskin Black And Decker
- Oppvaskmaskin Sauter
- Oppvaskmaskin Element
- Oppvaskmaskin Kucht
- Oppvaskmaskin Technika
- Oppvaskmaskin Hansa
- Oppvaskmaskin Thor
- Oppvaskmaskin Kenmore
- Oppvaskmaskin Meireles
- Oppvaskmaskin Fagor
- Oppvaskmaskin Edesa
- Oppvaskmaskin IFB
- Oppvaskmaskin Profilo
- Oppvaskmaskin Gaggenau
- Oppvaskmaskin Constructa
- Oppvaskmaskin KKT Kolbe
- Oppvaskmaskin Tisira
- Oppvaskmaskin Porter & Charles
- Oppvaskmaskin Zerowatt
- Oppvaskmaskin Baumatic
- Oppvaskmaskin Iberna
- Oppvaskmaskin Silvercrest
- Oppvaskmaskin Otsein
- Oppvaskmaskin Signature
- Oppvaskmaskin Corberó
- Oppvaskmaskin Daewoo
- Oppvaskmaskin Emerio
- Oppvaskmaskin Eurom
- Oppvaskmaskin Barazza
- Oppvaskmaskin Thermador
- Oppvaskmaskin Continental Edison
- Oppvaskmaskin Pitsos
- Oppvaskmaskin La Germania
- Oppvaskmaskin Emilia
- Oppvaskmaskin Esatto
- Oppvaskmaskin JennAir
- Oppvaskmaskin Blomberg
- Oppvaskmaskin Robinhood
- Oppvaskmaskin De Dietrich
- Oppvaskmaskin Zanussi
- Oppvaskmaskin Qilive
- Oppvaskmaskin Junker
- Oppvaskmaskin Benavent
- Oppvaskmaskin Black Decker
- Oppvaskmaskin Bellini
- Oppvaskmaskin Cookology
- Oppvaskmaskin Hanseatic
- Oppvaskmaskin Proline
- Oppvaskmaskin Pando
- Oppvaskmaskin Equator
- Oppvaskmaskin SEIKI
- Oppvaskmaskin Oranier
- Oppvaskmaskin Upo
- Oppvaskmaskin Sammic
- Oppvaskmaskin Ariston Thermo
- Oppvaskmaskin Hoonved
- Oppvaskmaskin Helkama
- Oppvaskmaskin Rex
- Oppvaskmaskin Classique
- Oppvaskmaskin Castor
- Oppvaskmaskin New World
- Oppvaskmaskin Essentiel B
- Oppvaskmaskin Bompani
- Oppvaskmaskin Prima
- Oppvaskmaskin Cove
Nyeste Oppvaskmaskin Manualer
5 August 2025
5 August 2025
5 August 2025
4 August 2025
4 August 2025
4 August 2025
4 August 2025
4 August 2025
4 August 2025
4 August 2025
