PN 2811849 April 2007
©2007 Fluke Corporation. All rights reserved. Printed in U.S.A.
1
Fluke-700HTH-1
Hydraulic Test Hose
Instruction Sheet
The Fluke-700HTH-1 Hydraulic Test Hose is designed to
work with the Fluke-700HTP-1 Hydraulic Test Pump. It is
self-sealing, with an easy, finger-tight connection, and low
volumetric expansion. The hose has the following
specifications:
Maximum pressure: 690 bar / 10,000 psi
Minimum bend radius: 60 mm / 2.36 in.
Working temperature: - 40 º ºC to + 120 C
( - 40 ºF to + 250 ºF)
Construction: nylon, stainless steel, zinc, plated steel,
and nitrile
Outer diameter: 6.0 mm (0.20 in.)
Fluids: water, mineral-based hydraulic oil
Box Contents
(1) .84 m (33 in) self-sealing hose assembly
(2) ¼ in NPT male hose fittings
(1) Adapter: 1/4 in NPT female to 1/4 in BSP male
Instruction Sheet
Contacting Fluke
To contact Fluke or for service, call one of the following
telephone numbers:
USA: 1-888-44-FLUKE (1-888-443-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
Or, visit Fluke's Web site at www.fluke.com
.
2
3
1
eve01f.eps
A Master Pressure Port
B Test Pressure Port
C Tee
B
A
A
eve02f.eps
A Hose Fitting
B Hose Assembly
