COMPONENT SPEAKER SYSTEMS

 CS-CM50 CS-CM60

PeakPower(Watts) 220 240

RatedPower(Watts) 35 40

FrequencyResponse 41Hz-26kHz 35Hz-26kHz

Impedance 4Ohms 4Ohms

Sensitivity 85dB 86dB

ConeMaterial Polypropylene Polypropylene

Tweeter PEI PEI

MountingDepth 43mm(1-11/16”) 45.5mm(1-13/16”)

MountingDiameter 118mm 126mm

 (4-21/32”) (5”)

CS-CM50 CS-CM60

WARNING:Donotdrillmountingholeswithspeakerinplaceasthiscouldallowdrillshavingstodamagethe

voicecoilandvoidyourwarranty.

SPEAKER PARAMETERS

www.fusionelectronics.com

TWEETER

Ø53mm

(2-1/16”)

9mm(11/32”)

20mm(25/32”)

47mm

(1-27/32”)

INSTALLATION GUIDELINES

Ensuretheaudiosystemisturnedoffbeforemakinganyconnections

totheamplier,speakersorsourceunit.Failuretodosocouldresultin

permanentdamagetotheaudiosystem.

Whenwiringthespeakersensurethatthewireisprotectedfromsharp

objectsandalwaysuserubbergrommetswhenwiringthroughmetal

panels.Ensureallterminalsandconnectionsareprotectedfromthe

vehiclechassisandfromeachotherasfailuretodosocouldresultin

permanentdamagetotheaudiosystem.

Whenconnectingthesourceunitandspeakersensureyouconnect

thepositiveandnegativeoutputwirefromthesourceunittothe

correspondingspeakerterminals.Thiswillensuretheaudiosystemwill

beinphase.



1) Ensurethereisadequateclearance&depthforthespeakertobe

 mounted

2) Usethesuppliedtemplatetomarkout&cutthecorrectdiameterhole

3) Drillfourholesforthemountingscrews

4) Seperatethegrillefromtheframe

5) Insertthespeaker&grilleframeandafxwiththescrewsprovided

6) Completeinstallionbyreplacingthegrilleintothegrilleframe

Produkspesifikasjoner

Merke:	Fusion
Kategori:	Høyttaler
Modell:	CS-CM50
Impedans:	4 Ω
Toppeffekt:	220 W
Diskanthøyttaler:	Ja
Nominell effekt:	35 W
Høyttalerdrivere:	5.25"
Separate komponenter:	Ja
Subwoofer inkludert:	Nei
Frekvensrekkevidde:	41 - 26000 Hz
Sensitivitet/følsomhet:	85 dB
Driversylinder, materiale:	Polypropylen
Innbygningsdybde:	43 mm
Diameter for monteringshull:	118 mm
