QUICK START GUIDE
VEGETABLE DICERS
MODELS
181DC14 - 1/4" Dice
181DC38 - 3/8" Dice
181DC12 - 1/2" Dice
181DC1 - 1" Dice
SAFETY INSTRUCTIONS
CAUTION
Be careful when handling and operating the machine, as
the blades are very sharp. Always keep your hands away
from the blades.
OPERATION
1. Place the unit on a sturdy work surface.
2. Core, slice, or cut the produce to prepare it for
chopping.
3. Lift the handle and place the produce on the blades.
4. Remove hands from the cutting area.
5. In one, uid motion, bring the push block down to
force the produce through the blades.
6. Lift push block and repeat as needed.
7. Clean the machine after chopping is complete using
the cleaning instructions below.
8. DO NOT chop produce larger than the opening in
the blade holder.
NOTE: To cut 1/4", 1/2", and 1", use the 1/4" push block.
To cut 3/8", use the 3/8" push block.
CLEANING
NOTE: Avoid using alkaline cleaners as they may dull the
nish and cause pitting.
1. Remove the handle, push block guide, bumpers, and
blade & holder assembly from the guide rods.
2. Wash the push block guide, push block, blade & holder
assembly, and frame thoroughly.
a. The push block can be removed from the push block
guide by removing the thumbscrews.
3. To disassemble the blade & holder assembly for
further cleaning:
a. Remove the screws and the blade holder plate.
b. Gently tap the blades and the blade spacers from
the blade holder.
CLEANING (CONTINUED)
4. To reassemble:
a. Place the blade holder on a sturdy surface with
the blade spacer pockets facing upward.
b. Insert the 4 blade spacers with their slots toward
the inner opening of the blade holder.
c. Insert blades with the sharp edge downward
and slots upward.
d. Insert blades with sharp edge and slots downward.
e. Reposition the blade holder plate and secure it
with screws.
f. Reposition the blade & holder assembly, bumpers,
push block, push block guide, and handle on the
frame.
5. When needed, lubricate the guide rods with mineral oil,
food grade grease, or parafn.
NOTE: DO NOT use cooking oil.
REPLACEMENT PARTS
BLADE ASSEMBLIES
#181PBA14 #181PBA38 #181PBA12 #181PBA1
1/4" 3/8" 1/2" 1"
BLADES
#181PBLD14 #181PBLD1#181PBLD38 #181PBLD12
1/4" (22 Blades) 3/8" (16 Blades) 1/2" (10 Blades) 1" (4 Blades)
PUSHER BLOCKS
#181PPB38 #181PPB1412
3/8" 1/4", 1/2", 1"
ADDITIONAL PARTS
#181BUMPER #181SSWNUT #181TSCREW #181FT1
Bumper Wingnut Thumb Screw Feet (4)
08/2023
