Side 1/24
Multi-Alert Receiver with doorbell
Récepteur d’alerte sans fil avec sonnette
Multi-Alarm-Empfänger mit Türklingel
English P2
Français P9
Deutsch P17
2
!!! Please refer to our website: www.geemarc.com for an up to date user guide, as there may
be important updates and changes you need to be aware of !!!
PACKAGE CONTENTS
The package contains the following items:
1 user’s manual
1 AMPLICALLTM100 (AC100) base
1 AMPLICALLTM101 (AC101) remote
1 AC power adapter
5 screws and 5 fixing holes
1 wall bracket and 1 lanyard bracket.
DESCRIPTION
Reset button
Function switch
* Chime
* Chime and Light
* Light
Vibration on indicator
Vibration ON/OFF
9V ready
Vibration out
Output delay
Relay output control
Power adapter jack
Wire clip
Flash light
Zone icon from 1 to 6
Speaker
Volume control
Learn melody
Melody selector
Battery compartment
Battery cover
3
INSTALLATION
Battery installation in the base
(needed in case of a power
failure)
1. Open the battery cover by
pulling it.
2. Insert three 1.5V LR14 alkaline
batteries (not provided) (C) into
the battery compartment, while
ascertaining that the polarity is
(+/-) .
3. Close the battery cover.
4. Plug the power cable into the
power adapter jack found on
the side of the AMPLICALL100
(A). Plug the adaptor into the
mains on the wall (B).
9V ready indicator: This indicator
will light up, when the 9V adaptor
is connected correctly.
LOW BATTERY INDICATOR ON THE AC100
If a zone icon LED light is blinking, it indicates that the battery power is too low for the
corresponding device (AC101, AC110 or AC140. You must replace the battery as
soon as possible.
If your AMPLICALL100 flash light blinks every 15 seconds, this indicates that the
AMPLICALL100 battery power is too low or that the batteries are not installed.
Please, disconnect the power and install new batteries.
AMPLICALLTM101
Put the bell press to the wall bracket or lanyard bracket
1. Place the mounting bracket that you have chosen (Fig 1 for the wall bracket or
Fig 2 for the lanyard bracket) to 90 degrees.
2. Rotate the mounting bracket until the part locks.
DC9V,1A
Fig1 or Fig2
