Gefen GF-HDK18G-VIP-TX Bruksanvisning
Gefen
Ikke kategorisert
GF-HDK18G-VIP-TX
Les nedenfor 📖 manual på norsk for Gefen GF-HDK18G-VIP-TX (4 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 11 personer og ble vurdert med 4.8 stjerner i gjennomsnitt av 6 brukere
Side 1/4
GF-HDK18G-VIP-TX
GF-HDK18G-VIP-RX
Extend and distribute 4K 60Hz 4:4:4 HDMI/USB-C Video,
Audio, RS-232, IR, USB, and Audio Return Path over a local
area network
Gefen Gen 3.0 KVM products offer enhanced performance, features,
and functionality such as 4K Ultra HD with HDR support, built-in scalling,
video-wall control, independent RS-232, IR, USB, and audio routing, USB
Roaming, OSD Hotkey Keyboard switching.
The Gefen GF-HDK18G-VIP-TX & RX feature maximum input resolution of
4K 60 Hz 4:4:4, and maximum output resolution of 4K 60 Hz 4:4:4. HDCP
2.3/2.2 and 1.4 are also supported. 7.1 channels of HBR (High Bit Rate)
lossless and LPCM digital audio can pass through the system as well.
Video, Audio, RS-232, 2-way IR, and USB can be routed independently
between any Sender and Receiver unit, allowing end-users to control any
of the sources and the displays within their network. Analog audio break-
out de-embeds audio from the video and sends it to a separate audio
system, enhancing the impact of presentations. Digital Optical Audio from
a Display is able to distribute to any Source location with an AV Receiver.
Applications include high performance AV and signage systems in sports
bars, clubs, restaurants, board and huddle rooms, command and
control centers, museums, airports, classrooms, auditoriums, hotels, and
retail establishments.
• HDR10, HDR10+, Dolby Vision
• HDCP 2.3, 2.2 and 1.4
• Deep Color
• Lip-Sync
• Uncompressed LPCM digital audio up to
7.1 channels
• Up to 7.1 channels of HBR (High Bit Rate)
digital audio including Dolby Atmos
®
,
Dolby
®
TrueHD, DTS:X
™
, and DTS-HD
Master Audio
™
Produkspesifikasjoner
| Merke: | Gefen |
| Kategori: | Ikke kategorisert |
| Modell: | GF-HDK18G-VIP-TX |
