Digital and Analog Versions
Owner’s Manual Revision E
ACU Firmware v1.16
RCU Firmware v1.16
XMOS Firmware v1.16
2
1 Welcome
Welcome and thanks for purchasing the Grace Design m905 reference monitor controller. We build all
of our products to be completely reliable and straightforward to use, so you can concentrate on doing
great work. While you will nd the m905 is fairly straightforward to use, it is a very powerful unit and a
great deal of user conguration is possible, so we recommend that you spend some time reading this
manual to help avoid any common user diculties.
In the event that you do encounter any technical diculties with this or any of our products, feel free to
call us at 303-823-8100. Our oce hours are 9:00 to 5:00, Monday through Friday, MST, or you may e-
mail any technical questions to: info@gracedesign.com. Also, please check out our website for complete
product information, owner’s manuals and technical documents http://www.gracedesign.com
Grace Design has been creating high quality products for the recording industry for 25 years. The
technology in the m905 is the result of extensive research, listening, testing and careful renement. Your
m905 represents a combination of pristine audio performance, robust mechanical construction and
complete reliability. We sincerely hope it helps you achieve a new level of excellence in your work!
Contents
1 WELCOME 2
2 IMPORTANT SAFETY INFORMATION 3
3 SAFETY MARKING SYMBOLS 3
4 SERVICE INFORMATION 3
5 M905 FEATURES 4
m905 Audio Control Unit Rear Panel 5
Audio Control Unit Front Panel 6
Remote Control Unit (RCU) 6
m905 Graphical User Interface 7
7 UNPACKING AND INSTALLING 8
Your m905 Box Will Contain 8
Open and Inspect the Box 8
Register Your Unit 8
8 CONNECTING THE M905 8
Power Connections 8
Power-Up Sequence 9
System Connections 9
9 NORMAL OPERATION MODE 11
Input Selection 11
Volume Control, Preset & Headphone Mute 12
Speaker Output Selection 12
Monitoring Option Controls 12
Display 15
Save / Recall of User Configuration 15
Optional IR (infrared) Remote Control Operation 15
Analog Only Option 17
Phono module option 17
10 SETUP MODE 17
Entering and Exiting Setup Mode 17
Input Setup 18
Speaker Setup 20
Dim Setup 22
SUB / DAC / METER setup 22
CUE Output Setup 23
Headphone Setup 23
Talkback Setup 24
Mute / (solo) 25
11 GENERAL SETUP 25
Display Setup 26
IR (infrared) Remote Setup 26
DIGI LOOP Setup 27
Digital Input Setup 27
System Setup 28
SPL Meter Setup 28
12 ABOUT CROSSFEED 28
13 COMMUNICATION ERROR HANDLING 29
14 COMPUTER AUDIO SETUP 30
Asynchronous USB Audio 30
USB Up Channel Setup 30
Computer Audio Requirements 32
Using the m905 for DAW playback 32
15 UPDATING FIRMWARE 32
Updating RCU Firmware 33
Updating ACU Firmware 34
Updating XMOS Firmware 35
16 SPECIFICATIONS 37
17 BLOCK DIAGRAM 39
18 PCB JUMPER LOCATIONS 40
19 WIRING DIAGRAMS 42
20 CLEANING AND MAINTENANCE 43
21 WARRANTY INFORMATION 43
22 MANUAL REVISIONS 44
