Growatt ARK 5.1-25.6XH-A1 Bruksanvisning
Les nedenfor 📖 manual på norsk for Growatt ARK 5.1-25.6XH-A1 (19 sider) i kategorien batteri. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/19
Download
Manual
Growatt New Energy
Shenzhen Growatt New Energy Co., Ltd
+86 755 2747 1942
www.ginverter.com
T
E
W
service@ginverter.com
GR-UM-242-A-01
ARK 5.1-25.6XH-A1 High Voltage Battery System
User Manual (V1.0)
4-13/F,Building A,Sino-German(Europe) Industrial Park,
Hangcheng Ave, Bao'an District, Shenzhen, China
Contents
1 Product Overview
2 Safety
3 Storage and Transportation
2.1 Basic security
2.2 Safety Precautions
2.3 Warning Labels
2.4 Emergency Responses
4 Installation
5 Power on/off Battery system
5 1 Power on Battery system
5.2 Power off battery system
.
6.1 Preparation
6.2 Battery pack or high voltage
controller replacement
6.3 System Failure Information List and
Troubleshooting Suggestions
1.1 Intended Use
1.2 Appearance
1.3 Working Principle and Function
3.1 Storage Requirements
3.2 Transportation Requirement
4 1 Basic Installation Requirements
4.2 Installation Required Tools
4.3 Installation Procedures
4.4 Electrical Connection
.
About this Document
This document describes the installation, electrical connection, operation, commission,
maintenance and troubleshooting of ARK 5.1-25.6XH-A1 Battery System (hereafter
simply put ARK XH-A1). Before installing and operating ARK XH-A1 system, ensure that
you are familiar with product features, functions, and safety precautions provided in this
document.
Symbol
Description
Indicates a potentially hazardous situation, if not avoided, could result
in serious injury or death.
WARNING
6 Maintenance Guide
7 Technical Specifications
Appendix I
7.1 ARK XH-A1(high voltage system)
7.2 BDC 95045-A1 (High voltage
controller)
7.3 ARK 2.5H-A1 (battery pack)
PV Array
Electrical Grid
AC
Breaker
The entire ARK XH-A1 high-voltage energy storage system includes a BDC 95045-A1
(High voltage controller) and multiple ARK 2.5H-A1(battery packs, Number of series less
than 10 ).
Each ARK 2.5H-A1 consists of 50Ah cells which form 51.2V voltage battery pack via one
parallel and sixteen serial connections (1P16S). Two to ten ARK 2.5H-A1 can be
connected in serial and extend the capacity and power of energy storage system.
The ARK XH-A1 battery system powers the loads through hybrid inverter (It can be
equipped with single-phase or three-phase, the following is just an example)at nighttime
without solar; when solar becomes available during daytime, solar energy powers the
loads as a priority and store residual solar power into the ARK XH-A1 battery system.
1 Product Overview
1.1 Intended Use
1
2
1.2 Appearance
1.2.1 BDC 95045-A1 (High voltage controller)
BDC 95045-A1 (High voltage controller) is composed of battery control unit (BCU),
Power control units, relay, DC breaker, power supply and communication terminals. The
appearance of the product is shown as below.
Fig 1.2: Schematic diagram of power panel
Location
Port
Function
1
POWER
Wake up battery.
2
INV
Port for communication with hybrid inverter.
3
Link-in
Battery system in parallel communication input
interface.
4
Link-out
Battery system in parallel communication output
interface.
5
BMU
Communication with the battery module.
6
Pressure relief valve
Pressures inside is released via the vent.
7
Module-
Connect to the negative power terminal of the
battery module.
8
Module+
Connect to the positive power terminal of the
battery module.
9
Ground terminal, connect to the battery module.
10
USB interface
USB interface.
11
LED1
Blue, 0%-25%SOC.
12
LED2
Blue, 26%-50%SOC.
13
LED3
Blue, 51%-75%SOC.
14
LED4
Blue, 76%-100%SOC.
15
Yellow Run light indicates normal operation.
Red ALM light indicates failure or protection status.
16
Breaker
Breaker to turn on/off the whole battery system
17
BAT+
The positive output from battery system to the
hybrid inverter.
18
BAT-
The negative output from battery system to the
hybrid inverter.
19
Ground terminal, connect to the hybrid inverter.
LED5
RUN
ALM
Dimension (unit: mm)
Fig 1.3: Dimension of BDC 95045-A1
EPS
Load
EPS
AC
Meter
Relay
Load
Battery
Inverter
Grid
Fig 1.1: System diagram of ARK XH-A1High voltage battery system
rirgf
日发电量 ：
10 KW. H
Automatic Switch Box
Fuse
