GBLI6532 Battery System Quick Installation Guidance
＊ Ensure to read the Guidance before installation in order to understand product
information and safety precautions.
＊ Operators should be well trained to fully understand grid-connected photovoltaic power
system and national/regional standards.
＊ Installers must use insulating tools and wear safety equipment.
＊ Device damages caused noncompliance with storage, transportation, installation and usage
requirements specified in Quick Guidance and Manual are not coved by Warranty.
!
CAUTION
1 Product Overview
LED 1
LED 2
LED 4
LED 5
LED 3
2
1
3
4
5
6
7
8
1
475
765
150
148
745
No. label Name No. label Name
1 POWER Power button 5 Link-out Parallel Network Output
2 + Positive terminal 6 Grounding terminal
3 _ Nagative terminal 7 PCS Network port to PCS
4 Link-In Parallel Network Input 8 Safety vent A vent to release pressure inside.
Shenzhen Growatt New Energy Technology CO.,LTD
2 Installation Process
2.1 Installation Location Requirements
＊ A manually operating breaker should be installed between battery and PCS to control
the main circuit under installation, wire connection and maintenance mode. The breaker
can be operated manually without using any tool. The distance between battery and the
breaker should comply with local regulations.
＊ Do not install or use battery near explosive or inflammable substances.
＊ Use battery in well-ventilated environment with temperature ranging from -10℃ to 50℃ .
＊ For outdoor installation, build sun & rain shade to avoid direct sunlight and rain exposure.
＊ Do not place battery upside down nor alongside as the above picture shown.
＊ Maintain a minimum level of dust and dirt in the environment.
!
CAUTION
2
θ≤5°
θ≤5°
Wall
Wall
Wall
Ground
500 ≤d≤1200
θ
90°
500 ≤d≤1200
500 ≤d≤1200
θ≤5°
Ground
Ground
Ground
Wall
Wall
Wall
θ
θ
90°
θ≤5°
Ground Ground
Wall
Wall
Ground
Wall
Wall
Shenzhen Growatt New Energy Technology CO.,LTD
