Growatt MIN 4200TL-X Bruksanvisning

Growatt solcelle MIN 4200TL-X

Les nedenfor 📖 manual på norsk for Growatt MIN 4200TL-X (27 sider) i kategorien solcelle. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/27

Installation

Operation Manual

MIN 2500TL-X

MIN 3000TL-X

MIN 3600TL-X

MIN 4200TL-X

MIN 4600TL-X

MIN 5000TL-X

MIN 6000TL-X

Shenzhen Growatt New Energy Technology CO.,LTD

No.28 Guangming Road, Shiyan Street, Bao’an District,

Shenzhen, P.R.China

No.28 Guangming Road, Shiyan Street, Bao’an District,

Shenzhen, P.R.China

GR-UM-155 A-01-

+86 0755 2747 1942 +86 0755 2747 1942

www.ginverter.comwww.ginverter.com

service@ginverter.comservice@ginverter.com

Download

Manual

Growatt New Energy

Index

1 Notes on this manual

2 Safety

3.1 TL-X Overview

3.2 Type label

3.3 Size and weight

3.4 Storage of Inverter

3.5 The advantage of the unit

2.1 Intended Use

2.2 Qualification of skilled person

2.3 Safety instruction

2.4 Assembly Warnings

2.5 Electrical Connection Warnings

2.6 Operation Warnings

1.1 Validity

1.2 Target Group

1.3 Additional information

1.4 Symbols in this document

1.5 Glossary

3 Product Introduction

4 Unpacking and inspection

5 Installation

5.1

5.2

5.3

Safety instructions

Selecting the installation location

Mounting the Inverter

6.1 Safety

6.2 Wiring AC Output

6.3 Connecting the second protective

conductor

6.4 Connecting the PV Array(DC input)

6.5 Connecting signal cable

6.6 Grounding the inverter

6.7 Active power control with smart

meter , CT or ripple control signal

receiver

6.8 Inverter demand response modes

(DRMS)

6.9 AFCI(Optional)

13.1 Dismantling the Inverter

13.2 Packing the Inverter

13.3 Storing the Inverter

13.4 Disposing of the Inverter

14.1 Specification

14.2 DC &AC connector info

14.3 Torque

14.4 Accessories

6 Electrical connection

13 Decommissioning

7 Commissioning

14 Technical Data

7.1 Start the inverter

7.2 General setting

7.3 Advanced setting

7.4 Communications

8.1 Start-Up the inverter

8.2 Turn-off the Inverter

9.1 Checking Heat Dissipation

9.2 Cleaning the Inverter

9.3 Checking the DC Disconnect

11.1 Error Messages displayed on

OLED

11.2 System fault

11.3 Inverter warning

11.4 Inverter fault

8 Start-Up and shut down

the inverter

15 Compliance Certificates

16 Contact

9 Maintenance and Cleaning

11 Trouble shooting

10 EU Declaration of Conformity

12 Manufacturer Warranty

Produkspesifikasjoner

Merke:	Growatt
Kategori:	solcelle
Modell:	MIN 4200TL-X
Innebygd skjerm:	Ja
Vekt:	10800 g
Bredde:	375 mm
Dybde:	160 mm
Høyde:	350 mm
Støynivå:	35 dB
Wi-Fi:	Ja
Skjermteknologi:	OLED
Utgangsstrøm:	19 A
Utgangsspenning (maks.):	280 V
Antall faser:	1
Utgangsfrekvens:	50/60 Hz
Startspenning:	100 V
Inngangsspenning (maks.):	550 V
Maksimal inngangseffekt (DC):	5880 W
Kortslutningsstrøm per MPPT (maks.):	16.9 A
Effektivitet (EU):	97.1
Produktfarge:	Hvit
Driftstemperatur (T-T):	-25 - 60 °C
Strømbeskyttelsesfunksjoner:	Over voltage, Reverse polarity, Short circuit
Internasjonal beskyttelses (IP)-kode:	IP65
Total Harmonic Distortion (THD):	3
MPP spenningsområde:	80 - 550 V
DC inngående spenning:	550 V
Maksimal styrke:	4200 W
Inngangsspenning (min.):	80 V
Utgangsspenning (min.):	180 V
Utgangseffekt kapasitet (max):	4.2 kVA
Overspennings kategori:	CAT II
