SYN 200-XH-US Quick Guide
Overview
Installation
2.1 System overview
2.2 Installation requirements
2.3 Wall mounting
1
3
2
3
4
5
1:Front panel
2:Grid indicator
3:Communication indicator
4:Status Indicator
5:Fault indicator
6:Inverter wiring port
7:Load wiring port
8:Grid wiring port
9:Heat sink
10:COM wiring port
11: Reserved wiring port
12:Generator wiring port
13:Wall mount bracket
No.
Name
Size
No.
Name
Size
1
Electric drill
Φ6mm
2
wrench
Φ3/8"
3
Allen wrench
4
Cross rise
Φ5mm
5
From flat
Φ1mm
6
Wire cutter
/
7
Wire stripper
/
8
hammer
/
3.
Electrical connection
3.1Electrical connection
2.4 Required tools
1 2 3 6
7 8
3.2 Connecting the SYN 200-XH-US to the Grid panel
≤15°
≥300mm
≥300mm
≥500mm
≥300mm
Inverter
SYN 200-XH-US
Grid
Generator
Batery
PV
4 5
A
Inverter
communication port
B
Generator control
port
C
Inverter wiring port
D
Inverter Ground
Terminals
E
Inverter Neutral
Terminals
F
Generator wiring port
G
Grid switch
H
Grid wiring port
I
Load Panel wiring
prot
J
Main Neutral
Terminals
K
Main Ground
Terminals
Use
Type
Size
1
Grounding Conductors
(Load/Generator/Inverters)
Yellow-green jacketed or
solid bare copper
6~1/0 AWG(Load/Generator)
10~8 AWG(Inverters)
2
AC output conductors
(Load/Grid)
Multi-color jacket,
copper
0-4/0AWG
3
Generator Input
conductors
4~0 AWG
4
Inverter Input
conductors
10~6 AWG
5
12V power
output conductors
Red and black multi-
color copper
16~14 AWG
6
Communication cable
CAT5E suggested
/
Cables prepared by the customer:
!
Note:
It is recommended to use two or three
polychromatic multi-core copper cables
cables for Grid/Load/ Generator/ Inverter
connection. Recommended using yellow-
green single multi-core cables for PE
connection. Recommended using shielded
twisted pair cable for RS485 connection.
≥300mm
D
H
Grid_L1 Grid_L2
Grid
N
PE
L1L2
N
PE
W
Load Panel
10 11 12 13
6 6 6 7 8 9
1
Grid
L1L2N
PE
L1
L2
3
Power wire
Communication wire
SYN 200-XH-US 447.5/17.62
Dimsesion W(mm/inch) H(mm/inch)
555.5/21.87 180.8/7.12
D(mm/inch)
3.3 Connecting the SYN 200-XH-US to the Load panel
1.Release the Allen screws of the upper cover and open the upper cover.
2.Install a conduit of the required diameter into the Grid conduit entry. Use the conduit
holder to support the conduit.
3.For versions with circuit breaker. Pull down the main breaker until it shows OFF.
Ensure that the main breaker is OFF, as shown in Figure 1.
4.Pass the cable from the grid through the grid conduit to the terminals of the circuit
breaker. Tighten the terminal screws with a torque of 310 in*lbs / 35N*m, as shown in
Figure 2.
5.For version without circuit breaker. Pass the cable from the grid through the grid
conduit to the GridL1 and GridL2 terminals of the SYN 200-XH-US. Tighten the terminal
screws with a torque of 310in*lbs / 35N*m, as shown in Figure 3.
6.Connect the neutral and grounding wires to the neutral and grounding terminals.
Tighten the terminal screws with a torque of 310in*lbs / 35N*m.
1.Install a conduit of the required diameter into the Loads conduit
entry. Use the conduit holder to support the conduit.
2.Pass the cable from the AC Loads panel through the Loads conduit
to the Load_L1 and Load_L2 terminals of the SYN 200-XH-US.
Tighten the terminal screws with a torque of 310in*lbs / 35N*m.
3.Connect the neutral and grounding wires to the neutral and
grounding terminals. Tighten the terminal screws with a torque of
310in*lbs / 35N*m, as shown on the right.
2
N
PE
OFF
ON
m m
Φ7/32"
Φ5/16"
A
B
C
D
E
F
G
H
I
J
K
ON
ON
ON
ON
Grid_L1 Grid_L2
N
PE
L1L2
N
PE
ON
AC Loads Panel
