Side 1/21

Wired Floor Heating Controller – 12

channels, motorised

HmIPW-FALMOT-C12

Installation and Operating Manual

Table of contents

1 Table of contents.................................................................................................3

2 Information about this manual.........................................................................3

3 Hazard information..............................................................................................3

4 General system information..............................................................................5

5 Function and device overview..........................................................................5

6 Start-up.................................................................................................................. 6

6.1 Screw mounting...........................................................................................................6

6.2 Rail mounting................................................................................................................7

6.3 Installation instructions...............................................................................................7

6.4 Installation..................................................................................................................... 8

6.5 Behaviour after switching on the power supply...................................................9

6.6 Pairing with a control unit.........................................................................................9

6.7 Configuration using the HomematicIP Wired Wall Thermostat..................... 10

6.8 Pairing another underfloor heating controller.................................................... 15

7 Operation............................................................................................................. 15

8 Troubleshooting.................................................................................................16

8.1 Command not confirmed........................................................................................16

8.2 Flash codes and display indicators........................................................................ 17

9 Restoring factory settings................................................................................ 19

10 Maintenance and cleaning............................................................................ 19

11 Disposal...............................................................................................................19

12 Technical specifications.................................................................................20

Documentation © 12/2024 eQ-3 AG, Germany

processes without the written consent of the publisher.

It is possible that this manual may contain typographical errors or printing errors. However, the information contained in this manual is reviewed on

a regular basis and any necessary corrections will be implemented in the next edition. We accept no liability for technical or typographical errors or

the consequences thereof. All trademarks and industrial property rights are acknowledged.

Changes in line with technical progress may be made without prior notice.

Version 1.1

Table of contents

1 Table of contents

1x Wired Floor Heating Controller – 12

channels, motorised

2 Information about this

manual

Read this manual carefully before begin-

ning operation with your HomematicIP

Wired device. Keep the manual for later

consultation. If you hand the device over

to other persons for use, please ask them

to read this manual.

Symbols used

This indicates a hazard.

This section contains important ad-

ditional information.

3 Hazard information

We accept no liability for damage

caused by use for other than the

intended purpose, incorrect han-

dling or failure to observe the haz-

ard warnings. In such cases, all war-

ranty claims are void. We accept no

liability for consequential damage.

Do not use the device if it has visi-

ble damage or a malfunction. If you

have any doubts, have the device

checked by a qualified expert.

For safety and licensing reasons

(CE), unauthorised conversions to

and/or modification of the device

are not permitted.

The device is not a toy – do not al-

low children to play with it.

Plastic film, plastic bags, polystyrene

parts, etc. can be dangerous for

children. Keep the packaging mate-

rial out of the reach of children and

dispose of it immediately.

Clean the device using a soft and

clean lint-free cloth. Do not use any

detergents containing solvents for

cleaning purposes.

Do not expose the device to mois-

ture, vibrations, constant solar or

other heat radiation, excessive cold

or mechanical loads. The device

must only be operated indoors.

Failure to observe the installa-

tion instructions may result in fire or

a danger of electric shock. The de-

vice is part of the building installa-

tion. Observe the relevant nation-

al standards and directives during

planning and installation.

The device is intended for operation

on the HomematicIP Wired Bus on-

ly. The HomematicIP Wired Bus

is a SELV power circuit. The mains

voltage for the building installation

and the HomematicIP Wired Bus

must be routed separately. Com-

mon cable routing for power supply

and the HomematicIP Wired Bus

in installation and junction boxes is

not permitted. The required isola-

tion for a power supply of the build-

ing installation to the HomematicIP

Wired Bus must be observed at all

times.

Produkspesifikasjoner

Merke:	Homematic IP
Kategori:	kontroll
Modell:	HmIPW-FALMOT-C12
Produkttype:	Elektrisk gulvvarme
Vekt:	440 g
Pakkevekt:	779.1 g
Produktfarge:	Grå
Pakkedybde:	97 mm
Pakkehøyde:	281 mm
Pakkebredde:	184 mm
Driftstemperatur (T-T):	0 - 50 °C
Internasjonal beskyttelses (IP)-kode:	IP20
Strøm (maks.):	0.375 A
