Instruction booklet

,1509)50-4

Contents

Installation, 2-5

Positioning and levelling

Technical data

Electrical connection

Connecting the water supply

Description of the appliance, 6

Overall view

Control panel

Loading the racks, 7

Lower rack

Cutlery basket

Upper rack

Start-up and use, 8-9

Starting the dishwasher

Loading the detergent

Washing options

Wash cycles, 10

Wash cycle table

Rinse aid and refined salt, 11

Loading the rinse aid

Loading the refined salt

Care and maintenance, 12

Shutting off the water and electricity supplies

Cleaning the dishwasher

Preventing unpleasant odours

Cleaning the sprayer arms

Cleaning the water inlet filter

Cleaning the filters

Leaving the machine unused for extended periods

Precautions and advice, 13-14

General safety

Disposal

Saving energy and respecting the environment

Troubleshooting, 15

After Sales Service, 16

After Sales Service

Essential Contact Information

Parts and Accessories

Appliance Registration

Hotpoint Guarantee, 17

.,,  '"

English, 1

Positioning and levelling

1. Remove the appliance from all packaging and check

that it has not been damaged during transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Check the dishwasher by placing it so that its sides or

back panel are in contact with the adjacent cabinets or

even with the wall. This appliance can also be recessed

under a single worktop

* (see the Assembly instruction

sheet).

3. Position the dishwasher on a level and sturdy floor. If

the floor is uneven, the front feet of the appliance may be

adjusted until it reaches a horizontal position (the angle of

inclination must not exceed 2 degrees). If the appliance is

levelled correctly, it will be more stable and much less

likely to move or cause vibrations and noise while it is

operating.

4*. Adjust the height of the rear foot from the front of the

appliance* on the central lower part of the dishwasher,

turning a hexagonal spanner (red color) with an opening

of 8 mm in a clockwise direction to increase the height

or in an anticlockwise direction to decrease the height.

Anti-condensation strip*

After installing the dishwasher, open the door and stick

the adhesive transparent strip under the wooden shelf in

order to protect it from any condensation that may form.

Keep this instruction manual in a safe place for

future reference. If the appliance is sold, given away or

moved, please ensure the manual is kept with the

machine, so that the new owner may benefit from the

advice contained within it.

Please read this instruction manual carefully: it

contains important information regarding the safe

installation, use and maintenance of the appliance.

If the appliance must be moved at any time, keep it

in an upright position; if absolutely necessary, it may be

tilted onto its back.

Advice regarding the first wash cycle

After the appliance has been installed, immediately

before running the first wash cycle, completely fill the

salt dispenser with water and add only then

approximately 1 kg of salt (see chapter entitled Rinse aid

and refined salt). The water may overflow: this is normal

and is not a cause for concern. Select the water

hardness value (see chapter entitled Rinse aid and

refined salt). - After the salt has been poured into the

machine, the LOW SALT indicator light

* switches off.

If the salt container is not filled, the water softener

and the heating element may be damaged as a result.

* Only available in selected models.

Installation

Technical data

Dimensions

width 60 cm

height 85 cm

depth 60 cm

Capacity 14 standard place-settings

Water supply

pressure

0,05 ÷ 1MPa (0.5 ÷ 10 bar)

7,25 – 145 psi

Power supply

voltage

See appliance data plate

Total absorbed

power

See appliance data plate

Fuse See appliance data plate

This dishwasher conforms to

the following European

Community Directives:

-2006/95/CE dated 16/01/2007

(Low Voltage) and subsequent

modifications

-89/336/EEC dated 03/05/89

(Electromagnetic Compatibility)

and subsequent modifications

-97/17/EC (Labelling)

-2002/96/ CE Waste Electrical

and Electronic Equipment

(WEEE)

The dishwasher meets the requirements set out by

the regulations in force concerning safety and electrical

equipment.

Any technical checks should be conducted

exclusively by a trained and authorised technician:

Repairs carried out by unaithorised persons will

invalidate the guarantee, as well as posing a potential

hazard to the user.

The manufacturer declines all responsibility for

damage to persons or property resulting from failure to

observe the above precautions, from tampering with

even a single component or from the use of non-original

spare parts.

Electrical Connection

Before inserting the plug into the electrical socket, make

sure that:

 the socket is earthed and complies with current

regulations;

 the socket can withstand the maximum load of the

appliance, which is indicated on the data plate

located on the inside of the door (see Description of

the appliance);

 the power supply voltage falls within the values

indicated on the data plate on the inside of the door;

 the socket is compatible with the plug of the

appliance. If this is not the case, ask an authorised

technician to replace the plug (see Assistance); do

not use extension cables or multiple sockets.

Once the appliance has been installed, the power

supply cable and the electrical socket should be easily

accessible.

The cable should not be bent or compressed.

If the power supply cable is damaged, it must be

replaced by the manufacturer or its Technical

Assistance Service in order to prevent all potential

hazards. (See Assistance)

This appliance must be earthed.

Fuses:your appliance comes fitted with a plug and a 13A

fuse. If you need to replace the fuse, only those rated at

13A and ASTA approved to BS1362 should be used. If

you lose the fuse cover, a replacement may be obtained

from your local authorised Service Centre or Electrical

company. Correct replacement is identified by colour

coding or the marking on base of plug.

DO NOT use the plug unless the fuse cover is fitted.

Changing the Plug

Cut off and dispose of the supplied plug if it does not

fit your socket.

To avoid a shock hazard DO NOT insert the

discarded plug into a socket anywhere else.

Wires in the mains lead are coloured accordance with

the following code:

Green/Yellow - Earth

Blue - Neutral

Brown - Live

If you change the plug, the colour of the wires in the

mains lead may not correspond with the terminal

markings in the plug, which if not coloured, could be:

EARTH E or

NEUTRAL N

LIVE L

Changing the Mains Lead

A lead can be ordered from Hotpoint Service

UK: 08709 066 066 or

Republic of Ireland: 1850 302 220

- If you have damaged the existing lead or require a

longer one a charge will be made. It is strongly advised

that this work is carried out by a qualified electrician.

- If the domestic wiring includes a residual current-

operated circuit breaker, ensure that it conforms to the

latest regulations.

The dishwasher must not be connected to the

electricity supply while installation is being carried out.

- This appliance should only be connected to a 230/

240V AC source, via a properly installed earthed socket.

- Use the dishwasher solely in a domestic environment.

- DO NOT stand or place heavy objects on the door

when it is open, this could damage the door or cause the

appliance to tip forward.

The Company shall not be held responsible for any

incidents that occur if these regulations are not

observed.

Produkspesifikasjoner

Merke:	Hotpoint
Kategori:	Oppvaskmaskin
Modell:	FDD914X
Bredde:	600 mm
Dybde:	600 mm
Høyde:	850 mm
Tørkesystem:	Naturlig
Støynivå:	42 dB
Vannforbruk per syklus:	13 l
Antall vaskeprogrammer:	12
AC-inngangsspenning:	220 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermtype:	LCD
Aquastop-funksjon:	Ja
Plassering av innretning:	Frittstående
Dør farge:	Sølv
Antall kuverter:	14 kuverter
Vaskeklasse:	A
Tørkeklasse:	A
Quick wash:	Ja
