Side 1/14

Manual IB-2242U2K

4x 2.5" U.2 SSD Backplane

Handbuch IB-2242U2K

4x 2,5" U.2 SSD Backplane

Safety information IB-2242U2K

Please read carefully the following information to prevent injuries, damage to material

and device as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate information in terms

of the probability of occurrence as well as the type and severity of the consequences if the measures to

prevent hazards are not complied with.

Warns of a directly hazardous situation causing death or serious injury.

Warns of a potentially hazardous situation that may cause death or serious

injury.

Warns of a potentially hazardous situation that may cause minor injury.

Warns of a potential situation that may cause material or environmental

damage and disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

• Do not cover the fan outlet and passive cooling elements

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	dataeske
Modell:	IB-2242U2K
Vekt:	708 g
Bredde:	140 mm
Dybde:	150 mm
Høyde:	41 mm
LED-indikatorer:	Access, Power
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	889 g
Materiale:	Aluminium, Metal
Antall per pakke:	1 stykker
SSD-formfaktor:	M.2
Antall skruer:	24
Størrelse:	5.25 "
Hot-swap:	Ja
Støttede lagringsstasjonshøyder:	15 mm
Dataoverføringshastighet:	32 Gbit/s
Antall eksterne SATA-porter:	1
Produktfarge:	Sort
Pakkedybde:	214 mm
Pakkehøyde:	80 mm
Pakkebredde:	195 mm
Modell/Type:	Driverbrett
Skruer inkludert:	Ja
Nøkkellås:	Ja
Antall SSD-er som støttes:	4
Støttede Windows operativsystemer:	Ja
Viftediameter:	40 mm
Antall vifter:	1 vifter
SSD drivergrensesnitt:	U.2
Antall nøkler som medfølger:	2 stykker
