Side 1/12

Quick installation guide IB-2281MSK

Backplane for 8x 2.5" SATA/SAS HDD/SSD in 2x 5.25" bay

Handbuch IB-2281MSK

Backplane für 8x 2,5" SATA/SAS HDD/SSD in 2x 5,25" Schacht

Safety information IB-2281MSK Safety information IB-2281MSK

Please read carefully the following information to prevent injuries, damage to material and device as

well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of

occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.

Warns of a directly hazardous situation causing death or serious injury.

Warns of a potentially hazardous situation that may cause death or serious injury.

Warns of a potentially hazardous situation that may cause minor injury.

Warns of a potential situation that may cause material or environmental damage and

disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

• Do not cover the fan outlet and passive cooling elements

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	diskrack
Modell:	IB-2281MSK
Vekt:	1522 g
Bredde:	163 mm
Dybde:	145 mm
Høyde:	85 mm
LED-indikatorer:	HDD, Power
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	1774 g
Materiale:	Aluminium, Metal
Antall per pakke:	1 stykker
USB-tilkobling:	Nei
Maksimal støttet lagringskapasitet:	- TB
HDD-grensesnitt:	SATA II, SATA III
Enhetsklasse:	Hjem og hjemmekontor
HDD-størrelse:	2.5 "
Størrelse:	2x 5.25 "
Hot-swap:	Ja
Støttede lagringsstasjonshøyder:	5, 7,9, 9.5, 12, 12.5, 12.7, 15 mm
Dataoverføringshastighet:	6 Gbit/s
Antall eksterne SATA-porter:	2
Produktfarge:	Sort
Pakkedybde:	213 mm
Pakkehøyde:	131 mm
Pakkebredde:	185 mm
Kabler inkludert:	miniSAS
Driftstemperatur (T-T):	0 - 55 °C
Harmonisert system (HS)-kode:	84733080
Modell/Type:	Driverbrett
Skruer inkludert:	Ja
Nøkkellås:	Ja
Støttede Windows operativsystemer:	Ja
Antall lagringsdrivere som støttes:	8
Intern:	Ja
Støttede Mac operativsystemer:	Ja
Viftediameter:	50 mm
Antall vifter:	2 vifter
Fullstendig installert lagringskapasitet:	0 TB
Kompatibel med Mac:	Ja
Installert lagringsdrivertype:	Nei
Støttet lagrings drive type:	HDD & SSD
Antall støttede HDDer:	8
Totalt installert lagerkapasitet:	0 GB
Grensesnitt for lagringsdriver:	Serial ATA III, Serial Attached SCSI (SAS) II
Lagringsstasjonens størrelse:	2.5 "
Hot-swap drive bays:	Ja
Antall nøkler som medfølger:	4 stykker
Lagerdrivere installert:	Nei
Mini-SAS-vertsport:	Ja
Driver-bay låsing:	Ja
Antall mini-SAS-vertsporter:	2
