Side 1/12

Manual IB-iR3521

Internal RAID for 2x 3.5" and 1x 2.5" HDD/SSD in 2x 5.25" bay

Handbuch IB-iR3521

Internes RAID für 2x 3,5" und 1x 2,5" HDD/SSD in 2x 5,25" Schacht

Safety information IB-iR3521 Safety information IB-iR3521

Please read carefully the following information to prevent injuries, damage to material and de-

vice as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate information in terms of the

probability of occurrence as well as the type and severity of the consequences if the measures to prevent

hazards are not complied with.

Warns of a directly hazardous situation causing death or serious injury.

Warns of a potentially hazardous situation that may cause death or serious

injury.

Warns of a potentially hazardous situation that may cause minor injury.

Warns of a potential situation that may cause material or environmental

damage and disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	diskrack
Modell:	IB-IR3521
Vekt:	1484 g
Bredde:	145 mm
Dybde:	140 mm
Høyde:	42 mm
LED-indikatorer:	Ja
Pakkevekt:	1674 g
Maksimal støttet lagringskapasitet:	- TB
Dataoverføringshastighet:	6 Gbit/s
Produktfarge:	Sort
Pakkedybde:	120 mm
Pakkehøyde:	180 mm
Pakkebredde:	254 mm
Kabler inkludert:	SATA
Driftstemperatur (T-T):	0 - 55 °C
Skruer inkludert:	Ja
Nøkkellås:	Ja
Støttede Windows operativsystemer:	Ja
RAID-nivåer:	0, 1,JBOD
Støttede lagringsgrensesnitt:	SAS-2, Serial ATA, Serial ATA II, Serial ATA III
Antall lagringsdrivere som støttes:	3
Antall vifter:	1 vifter
Fullstendig installert lagringskapasitet:	- TB
Kompatibel med Mac:	Ja
Støttet lagrings drive type:	HDD & SSD
Grensesnitt for lagringsdriver:	Serial ATA, Serial ATA II, Serial ATA III
Antall SATA-strømtilkoblinger:	2
Lagringsstasjonens størrelse:	2.5/3.5 "
Hot-swap drive bays:	Ja
SATA strøm-kontakt type:	SATA 15-pin
