Icy Box IB-868 Bruksanvisning

Icy Box minneleser IB-868

Les nedenfor 📖 manual på norsk for Icy Box IB-868 (2 sider) i kategorien minneleser. Denne guiden var nyttig for 7 personer og ble vurdert med 4.8 stjerner i gjennomsnitt av 4 brukere

Last ned PDF

Side 1/2

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

RaidSonic

STORAGE SOLUTIONS WITHOUT LIMITS

Key features

• Fast USB 3.0 card reader for MS/MS pro/MS pro duo

• Fits into a standard 3.5'' drive bay

• Front interfaces: 1x eSATA up to 3 Gbit/s,

1x USB 3.0 up to 5 Gbit/s, 1x USB 2.0 up to 480 Mbit/s

• Provides 1x USB 2.0 charging port, 5 V / 2.4 A

(Meets new USB battery charging BC 1.2 specification)

• Supports more than 60 memory cards (generic type of

cards are: CF I, CF II, MD, MMC, SD, SDHC, micro SD,

SDXC, RS, MS, MS Pro, MS Pro Duo, M2, EXD)

• OS independent

The IB-867 provides one USB 3.0 interface which need to be

connected to one internal 20 pin USB 3.0 connector on the

Mainboard.

IB-868

3.5" USB 3.0 Multi Card Reader

with USB charging port

Technical data

Model IB-868-B

Article nr. 20068

EAN Code 4250078186137

Brand ICY BOX

Article text 3.5" Multi Card Reader with

USB charging port

Colour Black

Material Plastic

Required space 1x 3.5"

Front port 1x USB 2.0, 1x USB 3.0, 1x eSATA,

6x card reader slot

Charging port provides 1x USB 2.0 charging port,

5 V, 2,4 A (BC 1.2)

Power connector Big-4Pin Molex

Operating system OS independent

Transfer rate USB 3.0 up to 5 Gbit/s,

eSATA up to 3 Gbit/s,

USB 2.0 up to 480 Mbit/s

LED Power and access

IB-868 in

3.5" drive bay

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

RaidSonic

STORAGE SOLUTIONS WITHOUT LIMITS

Logistical data

Packing unit: 10 pcs./carton Dimension/carton: 220x290x385 mm Import tax: 84716070

Total weight: 5.0 kg/carton Dimension of packing box:140x80x200 mm

Gross weight(incl. packing):0.45 kg Dimension of article: 102x24x120 mm

Net weight: 0.32 kg Country of origin: China

Makes the Computer More Sociable

Many peripherals can get in touch due to the multi-port front panel. 60

memory cards fit and can be read. The USB 3.0 port makes super fast

data transfer possible. The USB 3.0 card reader enables a much faster

data transfer. Especially the USB front charging port provides more

convenience by charging smartphones, Tablets and power bank.

Internal USB 2.0 interface for

1x USB 2.0 front interface

Big-4-Pin Molex

20 Pin USB 3.0 connector

for cardreader and USB 3.0

front interface

eSATA

USB 2.0 charging port

(5 V / 2.4 A)

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	minneleser
Modell:	IB-868
Vekt:	320 g
Bredde:	102 mm
Dybde:	120 mm
Høyde:	24 mm
LED-indikatorer:	Kraft indikator
Pakkevekt:	450 g
Antall USB 2.0-porter:	2
Inngangsspenning:	5 V
Dimensjoner (B x D x H):	102 x 120 x 24 mm
Minnespenning:	5 V
SIM-kortstøtte:	Nei
Integrert USB-kabel:	Nei
Produktfarge:	Sort
Minnekortenhet:	CF, CF+, MicroDrive, microSDHC, MMC, MS Duo, MS PRO, MS PRO Duo, MS PRO Duo Mark 2, SD, SDHC, SDXC
Pakketype:	Boks
Mikrofon, linje-inn-støpsel:	Nei
Kroppsmateriale:	Plast
USB-strøm:	Ja
Støttede Windows operativsystemer:	Ja
Intern:	Ja
Plugg inn og spill:	Ja
Strøm-LED:	Ja
Overføringshastighet (Mbps):	5000 Mbit/s
Pakningsstørrelse (BxDxH):	140 x 200 x 80 mm
USB 3.2 Gen 1 (3.1 Gen 1) antall porter:	1
Støttede drivbrønner:	3.5 "
