Quick installation guide IB-HUB1404A

USB 3.0 Desk Hub

Please read carefully the following information to prevent injuries, damage to material and device as

well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of

occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.

Warns of a directly hazardous situation causing death or serious injury.

Warns of a potentially hazardous situation that may cause death or serious injury.

Warns of a potentially hazardous situation that may cause minor injury.

Warns of a potential situation that may cause material or environmental damage and

disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

• Do not cover the fan outlet and passive cooling elements

• Avoid direct sunlight on the device/power unit

• Guarantee sufﬁcient ambient air for the device/power unit

• Do not place objects on the device/power unit

4. Hazards caused by very small parts and packaging

Risk of suffocation

Risk of death by suffocation or swallowing

• Keep small parts and accessories away from children

• Store/dispose of plastic bags and packaging in an area that is inaccessible to children

• Do not hand over small parts and packaging to children

5. Potential data loss

Data lost during commissioning

Potentially irreversible data loss

• Always comply with the information in the operating instructions/quick installation guide

• Exclusively use the product once the speciﬁcations have been met

• Back up data prior to commissioning

• Back up data prior to connecting new hardware

• Use accessories enclosed with the product

6. Cleaning the device

Harmful cleaning agents

Scratches, discolouration, damage caused by moisture or short circuit in the device

• Disconnect the device prior to cleaning

• Aggressive or intense cleaning agents and solvents are unsuitable

• Make sure there is no residual moisture after cleaning

• We recommend cleaning devices using a dry, anti-static cloth

7. Disposing of the device

Environmental pollution, unsuitable for recycling

Potential environmental pollution caused by components, recycling circle interrupted

This icon on product and packaging indicates that this product must not be disposed of as part of domestic

waste. In compliance with the Waste Electrical and Electronic Equipment Directive (WEEE) this electrical de-

vice and potentially included batteries must not be disposed of in conventional, domestic waste or recycling

waste. If you would like to dispose of this product and potentially included batteries, please return it to the

retailer or your local waste disposal and recycling point.

If you have any questions, please do not hesitate to contact our support at

support@raidsonic.de or visit our website at www.raidsonic.de.

WARNING

IMPORTANT

Safety information Safety information

Requirement for optional power adapter:

DC connector: G5 Connector, 3.5 mm x 1.35 mm

Input: AC 100-240 V

Output: Max. DC 5 V / 4 A

Packing content: 1x IB-HUB1404A, 1x Quick installation guide

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	minneleser
Modell:	IB-HUB1404A
Vekt:	156 g
Bredde:	68 mm
Dybde:	69 mm
Høyde:	70 mm
LED-indikatorer:	Ja
Pakkevekt:	256 g
Antall per pakke:	1 stykker
Utgangsstrøm:	5 V
Hot-swap:	Ja
Antall porter:	3
Kortleser:	2
Kabellengde:	1.2 m
Produktfarge:	Sort
Type strømforsyning:	USB
Pakkedybde:	200 mm
Pakkehøyde:	87 mm
Pakkebredde:	102 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Bærekraftsertifikater:	CE, Federal Communications Commission (FCC)
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	84719000
Kroppsmateriale:	Plast
Line-in:	Ja
Støttede Windows operativsystemer:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Plugg inn og spill:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Grensesnitt (hub):	3.5mm, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Overføringshastighet (Mbps):	5000 Mbit/s
Masterkassens (ytterkassens) bruttovekt:	12000 g
Masterkassens (ytterkassens) lengde:	535 mm
Produkter per masterkasse (ytterkasse):	40 stykker
Masterkassens (ytterkassens) bredde:	370 mm
Masterkassens (ytterkassens) høyde:	430 mm
Line-out:	Ja
