Icy Box IB-AC544 Bruksanvisning

Icy Box kabler for datamaskiner og annet IB-AC544

Les nedenfor 📖 manual på norsk for Icy Box IB-AC544 (1 sider) i kategorien kabler for datamaskiner og annet. Denne guiden var nyttig for 12 personer og ble vurdert med 4.9 stjerner i gjennomsnitt av 6.5 brukere

Last ned PDF

Side 1/1

Ra dS echn Gmbi onic T ology H • K t-Fiur sc sbhe 50 22926 Ahrenr-Straße • ur ermag / G ny

Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de

Of Tfers and deliveries are only done under our General erms and Conditions. Errors and omissions excepted .

RaidSonic

STORAGE SOLUTIONS WITHOUT LIMITS

Key features

•

Mini DisplayPort (male) to HDMI (female)

Resolution up to 4096x2160@60 Hz (4K)

Supports DisplayPort v1.2a with 1, 2 and 4 lanes (1.62, 2.7 and 5.4 Gbps)

Supports most common used audio formats

Supports up to 192kHz audio frame rate and up to 24-bit audio sample size

Supports multiple color formats:

- DP™: RGB 6/8/10/12 bit per component (bpc) and YCbCr4:4:4,

YCbCr4:2:2 8/10/12 bpc

- HDMI®: RGB 8/10/12 bpc; YCbCr4:4:4, YCbCr4:2:2 and YCbCr4:2:0

8/10/12 bpc

1.2V core power supply and 3.3V I/O power supply

Supports HDCP v2.2

Compact case

Plug & Play

How about 4K pixels?

T he terms H DMI and HDMI Hi - initigh Def on Mu lti ia med Interface, and H the DMI Logo are trademarks

or reg stered ademarks of cens ng the Un ted States and other countr i tr H LiDMI i LLC in i ies

Logistical data

Packing unit: Dimension/Carton: Import tax:50 pcs./carton 460x300x300 mm 84718000

Total weight/Carton: Dimension (color box):5.8 kg/carton 200x100x25 mm

Gross weight: Dimension of article:0.099 kg 51x35x14 mm

Net weight/article Country of origin:0.029 kg China

IB-AC544

Mini

The IB-AC544 Mini DisplayPort™ to HDMI® adapter can be used with all

PC´s or Notebooks with a DisplyPort™ interface. This adapter can mirror

or extend your display to any HDMI® screen up to 4K@60Hz resolution.

Mini DisplayPort to HDMI

ICY BOX IB-AC544

Adapter

Technical data

Model IB-AC544

Article nr. 60079

EAN Code 4250078164180

Brand ICY BOX

Article Text Mini DisplayPort to HDMI

adapter

Resolution Ultra HD 4K Up to 4096x2160@60 Hz

HDCP Support Version 2.2

Colour Black

Material Plastic

Chipset Parade PS176

Interface Mini DisplayPort (male), HDMI (female)

Supported OS Windows, Mac OS

Packing content 1x IB-AC544

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	kabler for datamaskiner og annet
Modell:	IB-AC544
Vekt:	29 g
Bredde:	51 mm
Dybde:	35 mm
Høyde:	14 mm
Maksimal oppløsning:	4096 x 2160 piksler
Opprinnelsesland:	China
Pakkevekt:	99 g
HDCP:	Ja
Antall per pakke:	1 stykker
Kabelfarge:	Sort
DisplayPort-versjon:	1.2a
Tilkobling 1:	Mini DisplayPort
Tilkobling 2:	HDMI
Produktfarge:	Sort
Pakkedybde:	100 mm
Pakkehøyde:	25 mm
Pakkebredde:	200 mm
Støttede videofunksjoner:	2160p
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
