70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
70-5700
INSTALLATION INSTRUCTIONS
Ford
1998-2001 Crown Victoria
2001-03
Escape
1998-2003
Explorer
2001-03
Explorer Sport Trac
2002-03
Ford Thunderbird
2002-03
Ford Thunderbird
1999-2003
Expedition (Early 2003
Production
Models)
2001-03
Mustang with Mach 460 or
Mach
1000 Sound systems
2004-05
Ranger
Lincoln
2003 Aviator
1998-2003
Continental
2000-03
LS
1999-2003
Navigator
1998-2001
Town Car
Mercury
1998-2003 Grand Marquis
1998-2003 Mountaineer
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
REV.
12/29/05
INST70-5700
Instructions:
Wire up the 16 and 20 way connectors of the
70-5700 per the EIA/Metra color code that can be
found on the back of this package. For vehicles
using the 8-way subwoofer plug, all vehicles will
use the top row of wires which are white (sub
input+), White/Black (sub input-), Black/White
(signal ground), and Blue/White (amp turn on).
For 2001-03 Ford Mustang and the 2000-03
Lincoln LS, they will use the bottom row of wires
also which are the gray (sub input+), Gray/Black
(sub input-), Black/White (signal ground), and
Blue/White (amp turn on).
The 2002-03 Ford Thunderbird will use both
top and bottom rows of wires with the exception
that the bottom row is for the center channel
speakers; Gray (center channel input +),
Gray/Black (center chanel input-), Black/White
(signal ground), and Blue/White (center channel
amp turn on).
Produkspesifikasjoner
| Merke: | Metra |
| Kategori: | kabler for datamaskiner og annet |
| Modell: | 70-5700 |
Trenger du hjelp?
Hvis du trenger hjelp med Metra 70-5700 still et spørsmål nedenfor, og andre brukere vil svare deg
kabler for datamaskiner og annet Metra Manualer
8 Oktober 2025
7 Oktober 2025
7 Oktober 2025
7 Oktober 2025
7 Oktober 2025
7 Oktober 2025
kabler for datamaskiner og annet Manualer
- Fusion
- Gembird
- IOGEAR
- Silverline
- Tripp Lite
- Vimar
- Fresh N Rebel
- Duronic
- Tributaries
- Black Box
- Vivotek
- 4smarts
- Genius
- Biltema
- Belkin
Nyeste kabler for datamaskiner og annet Manualer
5 Oktober 2025
5 Oktober 2025
4 Oktober 2025
4 Oktober 2025
4 Oktober 2025
4 Oktober 2025
4 Oktober 2025
4 Oktober 2025
4 Oktober 2025
4 Oktober 2025
