Side 1/16

Manual IB-LAN300-PCI

2.5 Gigabit PCIe Controller Card

Handbuch IB-LAN300-PCI

2,5 Gigabit PCIe Controller Karte

Safety information IB-LAN300-PCI

Please read carefully the following information to prevent injuries, damage to material and device as well

as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of

occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.

Warns of a directly hazardous situation causing death or serious injury.

Warns of a potentially hazardous situation that may cause death or serious injury.

Warns of a potentially hazardous situation that may cause minor injury.

Warns of a potential situation that may cause material or environmental damage and

disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3.Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

• Do not cover the fan outlet and passive cooling elements

• Avoid direct sunlight on the device/power unit

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	netverkskort/adapter
Modell:	IB-LAN300-PCI
Vekt:	35 g
Bredde:	13 mm
Dybde:	85 mm
Høyde:	35 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Opprinnelsesland:	China
Pakkevekt:	120 g
Nettverksstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u
Vertsgrensesnitt:	PCI Express
Maksimal dataoverføringshastighet:	2500 Mbit/s
Brikkesett:	Realtek RTL8125B
Komponent for:	PC
Produktfarge:	Sort, sølv
Pakkedybde:	140 mm
Pakkehøyde:	30 mm
Pakkebredde:	120 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Harmonisert system (HS)-kode:	85176990
Kroppsmateriale:	Metal, Plastic
Ethernet LAN dataoverføringshastigheter:	10,100,1000,2500 Mbit/s
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Videoopptaksgrensesnitt:	Ethernet
Intern:	Ja
Monteringsbeslag inkludert:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) bruttovekt:	5700 g
Masterkassens (ytterkassens) lengde:	425 mm
Produkter per masterkasse (ytterkasse):	40 stykker
Masterkassens (ytterkassens) bredde:	365 mm
Masterkassens (ytterkassens) høyde:	310 mm
Wake-on-LAN-forberedt:	Ja
