Side 1/2

U.2 SSD to PCIe 3.0 x4

U.2 SSD zu PCIe 3.0 x4

Key features

• Connected 2,5" U.2 (SFF-8639) NVMe SSD to PCIe 3.0 x4 slot

• Perfect for server, workstation and desktop

• Additional support for SATA III 6G

• Downwards compatible to PCIe 1.0, 2.0

• Operating system independent

Hauptmerkmale

• Verbindet eine 2,5" U.2 (SFF-8639) NVMe SSD zu PCIe 3.0 x4

• Ideal für Server, Workstations und Desktop PC

• Unterstützung für SATA III 6G optional

• Abwärtskompatibel zu PCIe 1.0, 2.0

• Betriebssystem unabhängig

Package content:

1x IB-PCI217, 1x Quick installation guide, 1x SATA cable, 1x Set of screws,

1x Screwdriver

Verpackungsinhalt:

1x IB-PCI217, 1x Schnellinstallationsanleitung, 1x SATA Kabel, 1x Schrau-

benset, 1x Schraubendreher

Installation: EN

1. Before starting the installation, turn off the computer and unplug it from

the power source.

2. Remove the cover of your computer, if there is one.

3. Plug your U.2 NVMe SSD into the U.2 (SFF-8639) connector of the

IB-PCI217 expansion card.

4. Fix the U.2 NVMe SSD from below with four screws on the IB-PCI217

expansion card.

5. Now carefully insert the IB-PCI217 expansion card with the installed

U.2 NVMe SSD into a free PCIe x16 slot in your system. Make sure

that the card is properly inserted and locked in place.

6. Fasten the slot bracket of the IB-PCI217 to your housing with a screw.

7. Close your housing and reconnect your computer to the power source.

8. Start your system.

Quick installation guide IB-PCI217

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	Ikke kategorisert
Modell:	IB-PCI217
Vertsgrensesnitt:	PCIe
NVMe:	Ja
Utgangsgrensesnitt:	U.2
Produktfarge:	Sort
Intern:	Ja
Dataoverføringsfrekvens (maks.):	32 Gbit/s
