Polarity Earth Status
3. 'Intelligent Earth' connection
The 4mm socket fitted to the AC iPurifier can be used to create a
supplementary Ground/Earth connection for audio systems
where there is no Ground/Earth present.
The supplementary Ground/Earth connection is ‘smart’ as it will
NOT introduce a ground loop EVEN if the system is already
Earthed (as more than one Earth also creates a ground loop).
4. Over-voltage Surge Protection
In the rare instance of excessive over-voltage OR a short in the
mains electricity, the over-voltage Surge Protection (OSP) is an
auto detection and cut-off circuit.
It will take several minutes for the AC iPurifier to reboot BUT if
the over-voltage or short persists, then the AC iPurifier will NOT
power on, thereby protecting the downstream audio system
from harm.
Disclaimer: Although the AC iPurifier does its utmost to protect the
audio system from electric harm, AMR/iFi does not guarantee this
as unpredictable circumstances can occur.
1. Operation
Insert into the wall outlet that supplies the audio system with
mains electricity OR insert into the mains extension block
powering the audio system.
Try both locations to determine which has the greatest sonic
impact.
Tips:
• Multiple AC iPurifiers can be used simultaneously in a system.
• The more AC iPurifiers used, the cleaner the overall power.
• On a power strip, if the AC iPurifier is placed in the middle, the
AC iPurifier will also act as a noise shield, noise is reduced,
isolated and confined to the respective left/right sections to
the AC iPurifier.
2. 'Smart Diagnostics' Polarity and Earth
The next table depicts the different readings and the respective
LED colour combinations. Where needed, make the necessary
system adjustments.
1
2
3
2
Polarity Error. Live and Neutral
connections are reversed.
Ground Error. Earth is missing
or faulty (e.g. resistance too high).
3
Red
In rare cases, AC iPurifier in auto
cut-out mode from over-voltage
or an electrical short.
4
Off Off
Red
Red
Specifications
Noise reduction:
Surge Protection:
Operating Voltage:
Size/Weight: (USA : )
(EU):
Warranty period:
warranty
In order to activate the warranty for this iFi
product, you must register with the iFi
website.
Component :
Serial no:
Terms & Conditions
ifi-audio.com
65.00 mm
ifi-audio.com Ver1.1
1
(LED) (LED)
Normal
GreenGreen
Green
> 40dB (> 100x)
max. 30,000A @ 1,000V/10uS
90V - 265V
ø 40mm x 105mm (L)
108 (g) / 0.24 (lbs)
ø 40mm x 115mm (L)
126 (g) / 0.28 (lbs)
12 months
205 mm
iFi guarantees that this iFi product shall be free from defects in materials and
workmanship for a period of 1 year for parts and labour.
The warranty period begins at the date of retail sale by an authorized iFi
distributor/dealer and is subject to the following requirements and
understandings:
• It is the responsibility of the buyer within 30 days from the original sale, to
register and activate the product warranty with the iFi website.
• The original invoice must be produced for authentication prior to any
warranty claim.
• The iFi product must not have been modified in any manner whatsoever,
or the warranty will immediately become void.
• The iFi warranty is only valid in the country of original sale.
• The product must not have been stored in a humid environment; nor
subjected to weather, water, or saltwater spray.
• iFi shall not, under any circumstances, be liable for any incidental or
consequential damages arising from the loss of property or other damage
or losses due to the failure of an iFi product. iFi is not liable for loss of use or
inconvenience caused by the failure of an iFi product. iFi is not liable for
damage caused to other audio components because of the failure of an iFi
product.
• During the warranty period, iFi will repair the product to working order, or,
at iFi's discretion, replace the defective module with a similar available
product.
• All repairs performed after expiry of the warranty period will be charged to
the owner and will carry a 180-day warranty on parts and labour. The
customer is responsible for shipping the unit to the iFi distributor in the
original packaging. This includes the payment of any shipping charges and
related taxes.
• Should any warranty issues arise, iFi’s decision is full and final.
