Side 1/16

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washer-dryer and

starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the drying cycle

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 11

General safety

Disposal

Care and maintenance, 12

Cutting off the water or electricity supply

Cleaning the washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 13

Service and Guarantee, 14-15-16

Before calling for Assistance

Guarantee

IWDC 6125 S

Instructions for use

WASHER-DRYER

English,1

Installation

 This instruction manual should be kept in a safe

place for future reference. If the washer-dryer is sold,

transferred or moved, make sure that the instruction

manual remains with the machine so that the new

owner is able to familiarise himself/herself with its

operation and features.

 Read these instructions carefully: they contain vital

information relating to the safe installation and

operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packaging.

2. Make sure that the washer-dryer has not been

damaged during the transportation process. If it has

been damaged, contact the retailer and do not

proceed any further with the installation process.

3. Remove the 4

protective screws (used

during transportation) and

the rubber washer with

the corresponding

spacer, located on the

rear part of the appliance

(see figure).

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need

them again if the washer-dryer needs to be moved to

another location.

 Packaging materials should not be used as toys for

children.

Levelling

1. Install the washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture cabinets

or anything else.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or loosening

the adjustable front feet

(see figure); the angle of

inclination, measured in

relation to the worktop,

must not exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive noise

and prevent it from shifting while it is operating. If it is

placed on carpet or a rug, adjust the feet in such a

way as to allow a sufficient ventilation space

underneath the washer-dryer.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to a

cold water tab using a ¾

gas threaded connection

(see figure).

Before performing the

connection, allow the

water to run freely until it

is perfectly clear.

2. Connect the inlet hose

to the washer-dryer by

screwing it onto the

corresponding water inlet

of the appliance, which is

situated on the top right-

hand side of the rear part

of the appliance (see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical details table (see

next page).

 If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

 Never use second-hand hoses.

 Use the ones supplied with the machine.

Connecting the drain hose

Connect the drain hose,

without bending it, to a

draining duct or a wall

drain situated between

65 and 100 cm from

the floor;

The drain hose may be

connected to an

under-sink trap. Before

connecting the drain

hose from the machine

ensure that any blanks

or removable ends

have been taken off

the spigot.

If it is place over the

edge of a basin or sink

be sure the free end of

the hose should not be

underwater.

 We advise against the use of hose extensions; in

case of absolute need, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Ensure that if the drain hose is pushed into a

standpipe, that the end does not go down more

than 15cms (6 inches). If the hose is pushed down

too far, this may cause the machine to self -syphon

ie. continuously empty as it is filling.

Electric connection

Before plugging the appliance into the mains

socket, make sure that:

 the socket is earthed and in compliance with the

applicable law;

 the socket is able to sustain the appliance's

maximum power load indicated in the Technical

details table (see page 5);

 the supply voltage is included within the values i

ndicated on the Technical details table

(see page 5);

 the socket is compatible with the washing

machine's plug. If this is not the case, replace

the socket or the plug.

Your appliance is now supplied with a 13 amp fused

plug it can be plugged into a 13 amp socket for

immediate use. Before using the appliance please

read the instructions below.

WARNING - THIS APPLIANCE MUST BE EARTHED.

THE FOLLOWING OPERATIONS SHOULD BE

CARRIED OUT BY A QUALIFIED ELECTRICIAN.

Replacing the fuse:

When replacing a faulty fuse, a 13 amp ASTA

approved fuse to BS 1362 should always be used,

and the fuse cover re-fitted. If the fuse cover is lost,

the plug must not be used until a replacement is

obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must be of the

correct colour as indicated by the coloured marking

or the colour that is embossed in words on the base

of the plug. Replacements can be obtained directly

from your nearest Service Depot.

Removing the plug:

If your appliance has a non-rewireable moulded plug

and you should wish to re-route the mains cable

through partitions, units etc., please ensure that

either:

the plug is replaced by a fused 13 ampere re-

wearable plug bearing the BSI mark of approval.

or:

the mains cable is wired directly into a 13 amp cable

outlet, controlled by a switch, (in compliance with BS

5733) which is accessible without moving the

appliance.

Disposing of the plug:

Ensure that before disposing of the plug itself, you

make the pins unusable so that it cannot be

accidentally inserted into a socket.

Instructions for connecting cable to an alternative plug:

Important: the wires in the mains lead are coloured in

accordance with the following code:

Green & Yellow Earth

Blue Neutral

Brown Live

65 - 100 cm

Where it connects to

the waste water pipe

cut end off spigot or

remove the blanking cap

Where it connects

to the waste water

pipe cut end off

spigot or remove the

blanking cap

Produkspesifikasjoner

Merke:	Indesit
Kategori:	Vaskemaskin
Modell:	IWDC 6125
Innebygd skjerm:	Nei
Vekt:	64000 g
Bredde:	595 mm
Dybde:	535 mm
Høyde:	850 mm
Dørhengsel:	Venstre
Antall tørkeprogrammer:	2
Energieffektivitetsklasse (gammel):	B
Tørkekapasitet:	5 kg
Antall vaskeprogrammer:	16
Vaskeprogrammer:	Hand/wool, Jeans/denim, Quick, Sport, Synthetics, Delicate/silk
Tørkeprogrammer:	Hurtig
Produktfarge:	Hvit
Pakkedybde:	590 mm
Pakkehøyde:	890 mm
Pakkebredde:	650 mm
Kontrolltype:	Buttons, Rotary
Sentrifugeringsklasse:	B
Støynivå (spinn):	60 dB
Lastetype:	Frontmatet
Plassering av innretning:	Frittstående
Forsinket start timer:	Ja
Trommelvolum:	52 l
Maksimal sentrifugeringshastighet:	1200 RPM
Justerbar spinnhastighet:	Ja
Belastningsbalansering:	Ja
Tittevindu:	Ja
Energiforbruk ved vask per syklus:	- kWh
Vaskeklasse:	A
Rinse Plus function:	Ja
Minimum spinnhastighet:	600 RPM
Energiforbruk ved vasking og tørking per syklus:	- kWh
Vannforbruk (vasking og tørking):	- l
Nominell kapasitet (vasking):	6 kg
Syklustid (vasking):	145 min
Syklustid (vasking og tørking):	180 min
Årlig energiforbruk (vasking og tørking):	972 kWh
Årlig vannforbruk (vasking og tørking):	20800 l
