Side 1/10
JBL
®
STAGE SERIES
LOUDSPEAKERS
ENGLISH
2
EN
ENGLISH
®
PRODUCT
For more than 68 years, JBL
®
engineers have been involved in every aspect of music and film recording and
reproduction, from live performances to the recordings you play on-the-go and in your home, car or oce.
We’re confident that the JBL system you have chosen will provide every note of enjoyment you expect – and that
when you think about purchasing additional audio equipment, you will once again choose JBL products.
INCLUDED ITEMS
Each box contains one or two loudspeakers, depending on the model, as indicated below.
A125C Speaker
A135C Speaker
Spikes
A190/A180/A170
Screws for Brackets
A120
Brackets
A120
Screws for Outrigger
A190/A180/A170
Feet Pad
A130/A120
Rubber Feet
A190/A180/A170
Foam Plugs
A120
Metal Levelling Feet
A135C/A125C
Outrigger
A190/A180/A170
Note: Attaching outrigger feet with spike or rubber feet.
A190 SpeakerA180 SpeakerA170 Speaker
A130 Speaker
A120 Speaker
3
EN
PLACEMENT
STAGE A190/A180/A170 – LEFT AND RIGHT CHANNELS
For best results, place the speakers 6 – 10 feet (1.8m – 3m) apart. Angling the speakers toward the listening
position can improve the stereo imaging. The speakers will produce the most accurate stereo soundstage when
the angle between the listener and the speakers is between 40 and 60 degrees.
Use the included carpet spikes for stability and improved performance if you are placing your Stage A190/A180/
A170 speakers on a thick rug or plush carpeting. The carpet spikes can be manually screwed into outrigger feet
provided.
CAUTION: Floorstanding (tower) loudspeakers have a high center of gravity and may become unstable and
tip over during earthquakes or if they are rocked, tipped or improperly positioned. Consider anchoring
these speakers to the wall behind them, using the procedures and hardware customary for anchoring
bookcases and wall units. You are responsible for proper installation and proper selection of hardware.
Generally, bass output will increase as the speaker
is moved closer to a wall or corner.
For best performance, we recommend that you
place the speakers at least 20 inches (51cm) away
from the side and rear walls.
FOAM PLUG
There are two operation modes for A120,
Bookshelfl oudspeaker & On-wall loudspeaker. In
the Bookshelf mode, A120 is the ported system
(port in rear), and in the On-wall mode, A120 is
semi-sealed system which requires a foam plug
inside the port.
WALL-MOUNTING THE STAGE A120
We have designed the Stage A120 speakers to mount
directly onto a wall. Each speaker has four keyholes on
the back and will require four 4.0x38mm wood screws
fastened to a wall stud. If a wall stud is unavailable,
install an anchor appropriate for a 4.0x38mm screw.
NOTE: You are responsible for the correct selection
and use of mounting hardware (available through
hardware stores) that will ensure the proper and safe
wall-mounting of the speakers. 4.0x38mm wood screws
not provided.
1) Using the included wall brackets, mark the positions
on the wall where you would like to place the
mounting screws.
2) Fasten four 4.0x38mm wood screws to the wall
using the markings from Step 1 as your guide.
Leave an 1/16" (1.59mm) space between the wall
and screwhead. If a wall stud is not available, use an
appropriate anchor.
3)
Place the speaker on the wall by aligning the keyholes
on the back of the speaker to the screwheads on the
wall.
Once positioned properly, the speaker should
slide down slightly and become secure.
6 – 10 ft
(1.8m – 3m)
40° – 60°
>20 in
(>51cm)
Keyholes
Keyholes
