DETAILED PLANNING DIMENSIONS GUIDE
(BASE UNIT REQUIRES SUITE-COORDINATING FULL HEIGHT PANEL KIT OR CUSTOM
PANELS AND HANDLES)
JB36NXFXRE, JB36NXFXLE โ€“ 35
3
โ„4" (W) x 82๎˜žโ„๎˜" (H) x 24" (depth without door panels/
handles)
BASE UNIT + FULL HEIGHT PANEL KIT = FINISHED REFRIGERATOR
Easily transform these overlay refrigerators into one of our signature kitchen suite designs with one of our suite-
coordinating stainless steel panel kits. To do so, you must order one of the overlay base units (left column) and one
of the suite-coordinating panel kits. The kits include refrigerator and freezer door panels, air grille and pre-installed
handles.
Base Unit
Model Number
Coordinating Stainless Full Height Panel Kits
RISEโ„ข
Stainless
NOIRโ„ข
Stainless
Bottom-Freezer
JB36NXFXRE
JB36NXFXLE
JBBFR36NHL
JBBFL36NHL
JBBFR36NHM
JBBFL36NHM
OPTIONAL ACCESSORIES FOR CUSTOM OVERLAY DESIGNS
ARMOIRE-STYLE DOOR PANEL KIT
W10663562 โ€“ 36" โ€“ Obsidian Interior
๎˜Ÿ For use with fully integrated and
๏ฌ‚ush refrigerators
๎˜Ÿ Enables installation and proper
venting of full height custom
door panels (not included) that
hide the top panel
๎˜Ÿ Includes left and right grille
brackets and machine
compartment cover
RISEโ„ข STAINLESS HANDLE KIT
W11231245 โ€“ Bottom-Freezer
๎˜Ÿ For use with Custom Overlay fully
integrated built-in refrigerators
NOIRโ„ข STAINLESS HANDLE KIT
W11194767 โ€“ Bottom-Freezer
๎˜Ÿ For use with Custom Overlay fully
integrated built-in refrigerators
W11356540A
2
๎š๎˜"๎˜„๎›ก๎š๎™ฏ๎˜ขY INT๎˜๎š–R๎œ‰T๎š๎˜š๎˜„๎šฉ๎œฑT๎š„O๎œฃ
F๎›‡๎˜๎˜๎›ธ๎›๎˜จ๎˜„๎›‡๎˜F๎›‡IG๎˜R๎œ‰T๎œฑR๎šฟ
DETAILED PLANNING DIMENSIONS GUIDE
(BASE UNIT REQUIRES SUITE-COORDINATING FULL HEIGHT PANEL KIT OR CUSTOM
PANELS AND HANDLES)
JB36NXFXRE, JB36NXFXLE โ€“ 35
3
โ„4" (W) x 82๎˜žโ„๎˜" (H) x 24" (depth without door panel/
handles)
Because Whirlpool Corporation policy includes a continuous
commitment to improve our products, we reserve the right to
change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details,
see Installation Instructions packed with product. Specifications
subject to change without notice.
PRODUCT DIMENSIONS
DIMENSION DESCRIPTION
JB36NXFXRE
JB36NXFXLE
A Width of door 35ยพ" (90.8 cm)
B
Overall width (including vinyl
side trims)
35ยพ" (90.8 cm)
C
Height of door handle
RISEโ„ข Stainless 40๎˜žโ„๎˜œ" (103.8 cm)
NOIRโ„ข Stainless
40๎˜›โ„๎˜œ" (103.2 cm)
D
Height to top of door handle
RISEโ„ข Stainless 49๎˜›โ„๎˜œ" (126 cm)
NOIRโ„ข Stainless
47๎˜š๎˜›โ„๎˜™๎˜˜"
(121.8 cm)
E Height of door 59๎˜šโ„๎˜—" (150.5 cm)
F
Space between door and
drawer
1/8" (0.3 cm)
G
Height to top of drawer
handle
RISEโ„ข Stainless 19๎˜›โ„๎˜™๎˜˜" (49.1 cm)
NOIRโ„ข Stainless
19๎˜–โ„๎˜œ" (49.2 cm)
H Height of drawer 20๎˜šโ„๎˜•" (52.1 cm)
I
Height of bottom grille
3" (7.6 cm)
J
Width from side of
refrigerator to handle โ€“ door
fully open 110ยฐ
RISEโ„ข Stainless 13๎˜žโ„๎˜™๎˜˜" (34.2 cm)
NOIRโ„ข Stainless
12๎˜š๎˜›โ„๎˜™๎˜˜" (32.8 cm)
K
Width from side of
refrigerator to handle โ€“ door
open 90ยฐ
RISEโ„ข Stainless 2๎˜–โ„๎˜œ" (6.1 cm)
NOIRโ„ข Stainless
1๎˜›โ„๎˜œ" (4.1 cm)
A
B
C
D
E
F
G
H
I
FRONT VIEW
J
K
110ยบ
TOP VIEW
