10WØv3-4
Subwoofers
owner’s manual
Congratulations on your purchase of a JL Audio subwoofer component. Your JL Audio subwoofer is a
precision loudspeaker which has been engineered to produce the highest quality sub-bass performance
in your vehicle. Authorized JL Audio dealers have extensive technical information for many different
applications of your new speaker. They also have the knowledge, skills and tools to build a high-quality
enclosure that will maximize the performance of your speaker. We highly recommend that you have your
enclosure built by an authorized JL Audio dealer.
Inside you will find specifications and two recommended enclosures for your speaker; one is a sealed
enclosure, the other is a ported design. Both types of enclosures will give you excellent sound quality and
low-frequency extension. The sealed enclosure is a better choice if space is extremely tight, but the ported
enclosure will produce 3dB more output at the same power if you have the extra space to work with.
2 JL AUDIO 10WØv3-4
SUBWOOFER 10WØv3-4
Free Air Resonance (Fs): 32.09 Hz
Electrical “Q” (Qes): 0.640
Mechanical “Q” (Qms): 10.752
Total Speaker “Q” (Qts): 0.604
Equivalent Compliance (Vas):
1.095 ft
3
31.01 liters
One-way, Linear Excursion (Xmax)*:
0.45 in.
11.4 mm
Efficiency (1W/1m)**: 84.07 dB SPL
Effective Piston Area (Sd):
48.909 in
2
0.0316 m
2
DC Resistance (Re): 4.280 ohm
Nominal Impedance: 4 ohm
Power Handling (continuous): 300 W
* Xmax specifications are derived via one-way voice coil overhang method
with no correction factors applied.
** Efficiency (1W/1m) is not an accurate indicator of a subwoofer’s output
capability and should not be used as a comparison to other subwoofers
to determine which one is “louder” !
A
B
E
D
C
10WØv3 SUBWOOFER
PHYSICAL SPECIFICATIONS
Nominal Diameter:
10.0 in.
250 mm
Overall Diameter (A):
10.52 in.
267 mm
Mounting Hole Diameter (B):
9.0625 in.
230 mm
Bolt Hole Circle (C):
9.7 in.
246.5 mm
Magnet Diameter (D):
5.05 in
128 mm
Mounting Depth (E):
4.9 in.
124 mm
Net Weight:
7.5 lbs.
3.40 kg
Driver Displacement:
0.034 ft
3
0.96 liters
JL AUDIO 10WØv3-4
U.S. PATENT: #6,219,431
