Side 1/6

SWR-1243D

12 Inch Dual Voice Coil Subwoofer (4Ω)+(4Ω)

Haut-parleur d'extrêmes graves à double bobine 12 po (4Ω)+(4Ω)

SWR-1223D

12 Inch Dual Voice Coil Subwoofer (2Ω)+(2Ω)

Haut-parleur d'extrêmes graves à double bobine 12 po (2Ω)+(2Ω)

SWR-1043D

10 Inch Dual Voice Coil Subwoofer (4Ω)+(4Ω)

Haut-parleur d'extrêmes graves à double bobine 10 po (4Ω)+(4Ω)

SWR-1023D

10 Inch Dual Voice Coil Subwoofer (2Ω)+(2Ω)

Haut-parleur d'extrêmes graves à double bobine 10 po (2Ω)+(2Ω)

TYPE-R SUBWOOFER

HAUT-PARLEUR D'EXTRÊMES GRAVES TYPE-R

APPLICATION GUIDE

GUIDE D' APPLICATION

TYPE-R WIRING WORKSHEET

CÂBLAGE POUR TYPE-R

DUAL 4

TYPE-R APPLICATION DIAGRAMS

SCH

MAS D'APPLICATION - TYPE-R, DOUBLE BOBINE, 4

Example 1

One Amplifier and One Subwoofer

Exemple 1

1 amplificateur et 1 h.-p. d'extr

mes graves

Example 2

One Amplifier and One Subwoofer

Exemple 2

1 amplificateur et 1 h.-p. d'extr

mes graves

Example 3

Two Amplifiers and One Subwoofer

Exemple 3

2 amplificateurs et 1 h.-p. d'extr

mes graves

Example 5

One Amplifier and Three Subwoofers

Exemple 5

1 amplificateur et 3 h.-p. d'extr

mes graves

Example 6

One Amplifier and Four Subwoofers

Exemple 6

amplificateur et 4 h.-p. d'extr

mes graves

Example 4

One Amplifier and Two Subwoofers

Exemple 4

1 amplificateur et 2 h.-p. d'extr

mes graves

SWR-1043D / SWR-1243D

JUMPER / CAVALIER JUMPER / CAVALIER JUMPER / CAVALIER

JUMPER / CAVALIER JUMPER / CAVALIER JUMPER / CAVALIER JUMPER / CAVALIER

SWR-1xxxD SWR-1xxxD SWR-1xxxD

SWR-1xxxDSWR-1xxxDSWR-1xxxDSWR-1xxxD

SWR-1xxxD

SWR-1xxxD SWR-1xxxD

SWR-1xxxD

JUMPER / CAVALIER JUMPER / CAVALIER

SWR-1xxxD

Produkspesifikasjoner

Merke:	Alpine
Kategori:	Bilhøyttaler
Modell:	SWR-1243D
Produkttype:	Subwoofer-driver
Bredde:	- mm
Dybde:	162 mm
Høyde:	- mm
Diameter:	275 mm
Produktfarge:	Sort
Kroppsmateriale:	Aluminium, Metal
kjøling:	Nei
Av/på-bryter:	Nei
Videoopptaksgrensesnitt:	Terminal
Fjerndrevet:	Nei
Subwoofer RMS-styrke:	600 W
Subwoofer-driverdiameter (imperisk):	12 "
Subwoofer-type:	Passiv
Frekvensomgang subwoofer:	24 - 200 Hz
Diameter på subwoofer-driver:	305 mm
Subwooferens toppeffekt:	1200 W
Svingspolediameter:	65 mm
Subwoofer-impedans:	4 Ω
Stemmespole type:	Dobbel
Subwoofer-driverens membranmateriale:	Kevlar
