APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2014 METRA ELECTRONICS CORPORATION
REV. 4/14/2014 INST82-9601
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Table of Contents
INSTALLATION INSTRUCTIONS FOR PART 82-9601
• Mounts aftermarket 6.5” to 6.75” speakers into
factory speaker locations.
• A) (2) speaker adapters • B) (6) #8 x 1” Pan-head Phillips screws
KIT FEATURES
KIT COMPONENTS
• Panel removal tool • Phillips screwdriver • Socket Wrench (T-25, T-27, 6mm or 3/16 hex)
TOOLS REQUIRED
Harley-Davidson 1998-2013
(FL models with fairings)
82-9601
A B
Fairing Disassembly
– Harley-Davidson FLH, batwing fairing
... 1998-2013 .......................................................2-3
– Harley-Davidson Roadglide, sharknose fairing
... 1998-2013 .......................................................4-5
Kit Assembly .......................................................... 6
82-9601
Fairing Disassembly
2
FLH/Batwing models:
1. Cover the front fender.
2. Remove (2) T-27 Torx bolts from inner
fairing (under mirrors) (Figure A, step 2)
3. Remove (2) T-27 Torx bolts from outer
edges of inner fairing near the fork tubes
(facing forward) (Figure A, step 3)
4. Remove (3) T-27 Torx bolts from bottom
edge of windshield. (Figure A, step 4)
NOTE: Windshield and fairing
will be loose once these screws
are removed. Use extreme
caution not to damage fairing or
windshield.
5. Remove windshield taking caution that
the outer fairing is loose.
Continued on next page
(Figure A)
Step 2 Step 2
Step 3
Step 4
