Side 1/3
KIT COMPONENTS
Speaker
Adaptor
Plates
82-3002
INSTALLATION
INSTRUCTIONS
APPLICATIONS
CAR PAGE
CHEVROLET
Pickup 1995-99........................................................ 1-2
Suburban 1995-99....................................................1-2
Tahoe 1995-99......................................................... 1-2
GMC
Sierra 1995-99......................................................... 1-2
Suburban 1995-99....................................................1-2
Yukon 1995-99.........................................................1-2
KIT FEATURES
Adapts 5¼" or
6½" speakers
to front door
locations
TOOLS REQUIRED
Window crank
removal tool
Phillips screwdriver
Cutting tool
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
1
ALL VEHICLES
ALL MODELS (EXCEPT SIERRA 1999, SILVERADO 1999): To mount the assembly with
clips, cut and remove mounting clips "A" and mounting tabs "C" from the Speaker Adaptor
Plates. To mount the assembly with screws (heavier speakers), cut and remove mounting
clips "A" only. (see Fig. A).
SIERRA 1999, SILVERADO 1999: Cut and remove mounting clips "B" from the Speaker
Adaptor Plates. (see Fig. B)
Disconnect the negative battery terminal to prevent an accidental short circuit. Using a
window crank removal tool, release the spring clip securing the window crank handle and
remove. Remove (2) Phillips screws from the armrest. Unclip the triangular trim piece in the
upper corner of the door panel. Pop out the cover cap from the upper-inside corner of the door
panel and remove (1) screw exposed. Using a small screwdriver, unclip the door latch trim and
remove. Unclip the perimeter of the door panel and remove the panel. (NOTE: The plastic
along the seam of the panel is very thin, use extreme care when removing). Unclip the factory
speaker (if present) and disconnect the wiring.
1
2
(PASSENGER SIDE
APPLICATION
SHOWN IN
ILLUSTRATION)
Fig. B
(USE THE FOLLOWING INSTRUCTIONS FOR EACH FRONT DOOR LOCATION).
"A"
"A"
"C"
Fig. A
"B"
