Smart Radio DAB+ and Smart Radio DAB+ Bluetooth
05.03.20211 / 80024075203
Smart Radio DAB+
Ref.-no.: DAB ..
Smart Radio DAB+ Bluetooth
Ref.-no.: DAB .. BT ..
Operating instructions
1 Safety instructions
Electrical equipment may only be tted and connected by electrically skilled persons.
Serious injuries, re or property damage possible. Read and observe instructions fully.
Danger of electric shock. Before working on the device, disconnect the mains voltage and switch o the
circuit breakers.
These instructions are a component part of the product and must remain with the end customer.
2 Correct use
- DAB reception in the frequency range 174 MHz to 240 MHz (VHF band III and channel 13)
- FM reception in the frequency range 87.5 MHz to 108 MHz (VHF band II)
- Installation in ush box according to DIN 49073 (recommendation: deep box)
3 Product characteristics
- Digital radio with display and sensor buttons
- Real glass front panel
- Stereo reception
- Connection terminals for two loudspeakers
- Stereo/mono switch-over
- Simple operation
- Integrated antenna for DAB+ and FM
- High reception quality
- Automatic station scan
- Storage of 8 favourites DAB+ and 8 favourites FM (will be retained after voltage failure)
- Switch-on with last station
- Switch-on with last volume
- Switch-on with last operation mode (DAB+ or FM)
- Display of station information, time and current settings
- Current time via RDS and DAB+
- Brightness level of display can be adjusted
- Night mode
- Alarm function
- Sleep mode
- Switching on/o via extension unit
- Line-out output (AUX) to connect external ampliers
- Optional external cable antenna ref.-no.: RAD-ANT
Only version with Bluetooth
- Playback and control of music on mobile devices via Bluetooth
- Storage of 8 Bluetooth audio sources
- Bluetooth device name can be changed
GB
Smart Radio DAB+ and Smart Radio DAB+ Bluetooth
05.03.20212 / 80024075203
4 Structure of the device
1. Power supply
2. Frame
3. Display
4.
next/previous channel/title
loud/quiet, brighter/darker
5. Button On/O
6. Conrm/apply button
7. Button
Selection DAB+, FM, Bluetooth, Alarm, Settings, Return without saving
8. Favourites button
1
2
3
4
5
6
7
8
Fig. 1: Structure of the device
5 Operation
Switch on/o
• Press
button
Radio switches on/o
Menu
• Press
button.
• Select functions with
buttons: DAB RADIO, FM RADIO, BLUETOOTH, ALARM, SETTINGS
• Selection with
button.
• SETTINGS submenu:
SLEEP, TIME, DISPLAY, BT-NAME
• Selection with button.
DAB RADIO/FM RADIO
During commissioning, all reachable channels are saved. The next/previous channel is selected using the
buttons.
The choice between DAB RADIO and FM RADIO is made using the menu
.
Saving favourites
During commissioning, the 8 strongest channels are saved as favourites.
The favourites can be customised individually.
• Selecting channels
• Press
button longer.
• Select favourite 1-8 using button
• Press
button.
Channel is saved on the selected favourite.
Smart Radio DAB+ and Smart Radio DAB+ Bluetooth
05.03.20213 / 80024075203
Retrieving favourites
• Press
button briey.
• Select favourite 1-8 using button
.
The respective channel is displayed and played.
• Conrm channel using
button
Channel search
• Press
button for 3 seconds
Display shows “New Scan”
• Conrm scan using
button
Night mode
In night mode the display can be hidden if the radio is switched o. After pressing any button, the display becomes
visible for approx. 10 seconds.
Requirement: For activating the night mode the radio has to be switched o.
• Select the lowest brightness level using
button.
• Press
again to de/activate night mode.
SLEEP
The radio switches o after a predetermined time. The OFF setting deactivates the function.
• Hold down
button for 3 seconds.
• Set (OFF, 15 min, 30 min) using
buttons
• Conrm
button
Setting time
The time is transferred from favourite 1 via DAB+ or FM. If the time is not transferred via DAB+ or FM, it must be set
manually.
• Press
button.
• Select SETTINGS and then TIME using
button.
• Conrm
button
• Set time using
buttons.
• Conrm
button
Alarm time/alarm function
The last radio channel is selected as alarm sound. The volume increases gently.
Setting alarm time:
Requirement: The radio is switched o.
• Press
button for approx. 4 sec
• Setting alarm time using
buttons
• Press
button
Alarm time is set.
Alarm function is active
Switching alarm function on/o:
Requirement: The radio is switched o.
• Press
button for approx. 2 sec.
ALARM ON or ALARM OFF is displayed briey.
Activated alarm time appears in the upper right-hand corner of the display.
