Jung R AN AL 2914 Bruksanvisning
Les nedenfor 📖 manual på norsk for Jung R AN AL 2914 (8 sider) i kategorien radioer. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/8

Stereo Radio
Art.No.: R AN..514..
R AN..914..
ALBRECHT JUNG GMBH & CO. KG
Volmestrasse 1
58579 Schalksmühle, Germany
mail.info@jung.de
www.jung.de
GB

Safety instructions
Caution! Electrical devices may only be installed and tted by electrically
skilled persons.
Non-compliance with the installation information could cause damage to the
device, re or other hazards.
Danger of electric shock. Before working on the device, disconnect the power
or load and switch off the circuit breakers.
Danger of electric shock. Loudspeaker connections and power supply may not
be wired in one socket.
These instructions are a component part of the product and must remain with
the end customer.
Structure of the device
1
2
3
4
56
7
Figure 1: Structure of the radio device
1. Radio
2. Button set
3. Plastic screws
4. Frames
5. Supporting ring with power supply
6. Lever
7. Power supply interface

Function
Correct use
• Installation in two concealed appliance boxes according to DIN EN 49073
(recommendation: deep boxes).
• VHF reception in the frequency range 87.5 MHz to 108 MHz
Product characteristics
• Stereo reception
• Connection terminal for additional external loudspeaker (right stereo channel)
• Automatic recognition of the second loudspeaker
• Automatic switching from mono to stereo operation when there is sufcient
signal strength and a second loudspeaker is connected
• Simple operation with additional feedback LED
- Blue LED lit up: operational display
- Blue LED ashing: Sleep mode active
- Red LED lit up: favourite channel
• High-quality sound and large loudspeaker dynamics
• Optimised acoustics through the use of a base reex tube
• Integrated VHF aerial
• High reception quality
• Automatic and manual channel search
• Non-volatile storage of 4 favourite channels (saved channels remain stored
when power supply fails)
• Switch on with most recent channel and saved volume
• Sleep mode (switch-off after approx. 30 minutes)
• Switching on/off possible via extension connection together with the room
lighting
• Switching on/off via potential-free contact A/B (e.g. switch or timer switch with
potential-free contact).
Operation
Switching radio on/off
• Press button briey
Device switches on/off.
The blue LED lights/switches off
iThe most recently set channel will be called up with the most recently set
volume.
Sleep mode
The radio is switched on.
• Press and hold button (approx. 3 seconds).
The long press will be acknowledged with a sound.
The blue LED ashes.
The radio switches off after approx. 30 minutes.
Produkspesifikasjoner
Merke: | Jung |
Kategori: | radioer |
Modell: | R AN AL 2914 |
Bruksanvisning: | Ja |
Innebygde høyttalere: | Ja |
Volumkontroll: | Digitalt |
Materiale: | Termoplast |
Inngangsspenning: | 230-240 V |
FM-antenne: | Ja |
Radio: | Personlig |
FM-bånd: | 87.5 - 108 MHz |
AC-inngangsfrekvens: | 50 - 60 Hz |
Produktfarge: | Hvit |
MP3-avspilling: | Nei |
Driftstemperatur (T-T): | 0 - 50 °C |
Relativ luftfuktighet under drift (H-H): | 15 - 90 |
RMS-rangert strøm/utgangseffekt: | - W |
Mottakertype: | Digitalt |
Støttede radiobånd: | FM |
