Side 1/36

KRC-478R

KRC-478RV

KRC-378R

KRC-33R

B64-1531-00 (EY)

CASSETTE RECEIVER

INSTRUCTION MANUAL

— 2 —

English

Contents

Before use

Safety precautions ........................................................................3

General features

Power............................................................................................5

Volume..........................................................................................5

Switching Modes ..........................................................................6

Attenuator .....................................................................................6

Loudness ......................................................................................6

Audio Control Setting....................................................................6

Clock display .................................................................................7

TEL Mute ......................................................................................8

Theft Deterrent Faceplate.............................................................8

Tuner features

Tuning ...........................................................................................9

Station Preset Memory...............................................................10

Clock display ...............................................................................10

RDS features

RDS (Radio Data System) ...........................................................11

Enhanced Other Network ...........................................................11

Alarm...........................................................................................11

Traffic Information Function........................................................11

Presetting Volume for Traffic Information/News ........................12

Programme Type (PTY) Function ................................................12

Cassette player features

Playing Cassette Tapes...............................................................14

Fast Forwarding and Rewinding Cassette Tapes........................14

Blank Skip....................................................................................14

Tape Advance .............................................................................14

Music Repeat..............................................................................15

External disc control features

Playing Disc mode.......................................................................16

Fast Forwarding and Reversing Disc Play...................................16

Track Search................................................................................16

Disc Search .................................................................................17

Track / Disc Repeat .....................................................................17

Track Scan...................................................................................17

Disc Scan ....................................................................................18

Random Play ...............................................................................18

Magazine Random Play...............................................................18

Text / Title Scroll..........................................................................18

Presetting Disc Names ...............................................................20

Switching Display for Discs.........................................................21

Menu settings

Menu System..............................................................................22

Touch Sensor Tone .....................................................................22

Manual Time Adjustment............................................................22

Automatic Time Adjustment .......................................................22

Disabled System Indicator (DSI)..................................................23

Selectable Illumination ................................................................23

News Bulletin Function with PTY News Timeout Setting...........23

Local Seek Function....................................................................23

Selecting Tuning Mode ...............................................................24

Auto Memory Entry.....................................................................24

AF (Alternative Frequency) Function...........................................24

Restricting RDS Region (Region Restrict Function) ....................24

Auto TP Seek Function................................................................25

Monaural Reception....................................................................25

Text Scroll ...................................................................................25

Installation

Accessories.................................................................................26

Installation Procedure..................................................................26

Connecting Cables to Terminals .................................................27

Installation...................................................................................30

Troubleshooting guide........................................32

Specifications .....................................................35

— 3 —

To prevent injury and/or fire, take the

following precautions:

• Insert the unit all the way until it is fully

locked in place. Otherwise it may fly out of

place during collisions and other jolts.

• When extending the ignition, battery or

ground cables, make sure to use automotive-

grade cables or other cables with an area of

0.75mm

(AWG18) or more to prevent cable

deterioration and damage to the cable

coating.

• To prevent short circuits, never put or leave

any metallic objects (e.g., coins or metal

tools) inside the unit.

• If the unit starts to emit smoke or strange

smells, turn off the power immediately and

consult your Kenwood dealer.

• Make sure not to get your fingers caught

between the faceplate and the unit.

• Be careful not to drop the unit or subject it to

strong shock.

The unit may break or crack because it

contains glass parts.

• Do not touch the liquid crystal fluid if the LCD

is damaged or broken due to shock. The

liquid crystal fluid may be dangerous to your

health or even fatal.

If the liquid crystal fluid from the LCD

contacts your body or clothing, wash it off

with soap immediately.

2WARNING

To prevent damage to the machine,

take the following precautions:

• Make sure to ground the unit to a negative

12V DC power supply.

• Do not open the top or bottom covers of the

unit.

• Do not install the unit in a spot exposed to

direct sunlight or excessive heat or humidity.

Also avoid places with too much dust or the

possibility of water splashing.

• Do not set the removed faceplate or the

faceplate case in areas exposed to direct

sunlight, excessive heat or humidity. Also

avoid places with too much dust or the

possibility of water splashing.

• To prevent deterioration, do not touch the

terminals of the unit or faceplate with your

fingers.

• Do not subject the faceplate to excessive

shock, as it is a piece of precision equipment.

• When replacing a fuse, only use a new one

with the prescribed rating. Using a fuse with

the wrong rating may cause your unit to

malfunction.

• To prevent short circuits when replacing a

fuse, first disconnect the wiring harness.

• Do not place any object between the

faceplate and the unit.

• During installation, do not use any screws

except for the ones provided. The use of

improper screws might result in damage to

the main unit.

2CAUTION

IMPORTANT INFORMATION

You cannot connect the unit directly to the

following CD automatic changers. For users

who want to use older changers with the

unit, follow the directions below according to

the type of changer you own:

• KDC-C200 / KDC-C300 / KDC-C400

Use the extension cable and the control box

attached to the CD changer, and the optional

CA-DS100 converter cable.

• KDC-C301 / KDC-C600 / KDC-C800 / KDC-

C601 / KDC-C401

Use the extension cable attached to the CD

changer, and the optional CA-DS100

converter cable.

• KDC-C100 / KDC-C302 / C205 / C705 /

non-Kenwood CD changers

Cannot be used with this model.

You can damage both your unit and

the CD changer if you connect them

incorrectly.

2CAUTION

Safety precautions

Produkspesifikasjoner

Merke:	Kenwood
Kategori:	Mottaker
Modell:	KRC-378R
Vekt:	1400 g
Maksimal inngangseffekt:	160 W
Impedans:	600 Ω
Dimensjoner (B x D x H):	182 x 158 x 52 mm
FM-bånd:	87.5 - 108 MHz
Maksimalt inngangsnivå:	14.4 V
Produktfarge:	Sort
Signal-til-støy-forhold (SNR):	54 dB
RMS-rangert strøm/utgangseffekt:	104 W
Støttede radiobånd:	FM, LW, MW
Utjevner/frekvenskorrigerer:	Ja
RDS-mottaker inkludert:	Ja
Frekvensrekkevidde:	30 - 14000 Hz
Utgangsstrømbeskrivelse:	4 x 26 W
