Side 1/11
KXMA400.2 | KXMA1200.2
KXMA400.4
Manual del Propietario | Español
AMPLIFICADOR DEL LA SERIE KXM.2
Benutzerhandbuch | Deutsch
STEREOVERSTÄRKER DER KXM.2-SERIE
Manuel d’utilisation | Française
AMPLIFICATEUR DE SÉRIE KXM.2
KXM
AMPLIFIERS
Owner’s Manual
2
KXM STEREO-SERIES AMPLIFIERS
OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no
items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm)
of open ventilation for the amplifi er. If possible, mount the amplifi er in the climate-controlled passenger
compartment. Drill four holes using a 7/64” (3mm) bit and use the supplied #8 screws to mount the
amplifi er.
Wiring: The KXM amplifi er’s RCA inputs will receive either high or low level signals from your car stereo’s
source unit. A high-level signal can be run from the source unit’s speaker outputs to the stereo RCA
input on the end panel of the amplifi er using the KICKER KISL as shown. Alternatively, the signal can be
delivered to the amplifi er using the low-level RCA outputs on the source unit. Keep the audio signal cable
away from factory wiring harnesses and other power wiring. If you need to cross this wiring, cross it at a
90 degree angle.
PERFORMANCE
MODEL: KXMA400.2 | KXMA1200.2 | KXMA400.4
IMPORTANT SAFETY WARNING
PROLONGED CONTINUOUS OPERATION OF AN AMPLIFIER, SPEAKER, OR SUBWOOFER
IN A DISTORTED, CLIPPED OR OVER-POWERED MANNER CAN CAUSE YOUR AUDIO
SYSTEM TO OVERHEAT, POSSIBLY CATCHING FIRE AND RESULTING IN SERIOUS
DAMAGE TO YOUR COMPONENTS AND/OR VEHICLE. AMPLIFIERS REQUIRE UP TO 4
INCHES (10CM) OPEN VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT
LEAST 1 INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY
SURFACE.
Model: KXMA400.2 KXMA1200.2 KXMA400.4
RMS Power
@ 14.4V, 4 stereo, ≤ 1% THD+N
@ 14.4V, 2 stereo, ≤ 1% THD+N
@ 14.4V, 4Ω mono, ≤ 1% THD+N
100 x 2
200 x 2
400 x 1
300 x 2
600 x 2
N/A
50 x 4
100 x 4
200 x 2
Length [in, cm] 9-9/16, 24.4 11-3/16, 28.4 11-3/16, 28.4
Specifi cations common to all models:
Height [in, cm] 2-1/8, 5.5
Width [in, cm] 8-5/16, 21
Frequency Response [Hz] 10Hz–20kHz
Signal-to-Noise Ratio [dB] 95dB
Input Sensitivity 250mV–10V
Selectable Electronic Crossover Off; Variable HP, 10–500Hz; Variable LP, 40–500Hz; 400Hz–5,000Hz
with 10X Switch (bandpass capable); Slope: 24dB/octave"
KickEQ™ Bass Boost 0–18dB @ 40Hz
3
Install a fuse within 7” (18cm) of the battery and in-line with the power cable connected to your amplifi er.
POWER WIRING
source unit
high-level speaker
outputs
to amplifi er
shield
+
–
core conductor
KICKER KISL (optional)
from source unit high-
level speaker outputs
OR
to amplifi er
Model External Fuse
(sold separately)
Power/Ground Wire KICKER Wiring Kit
KXMA400.2 1 x 60 Ampere 8 Gauge PK8, CK8
KXMA1200.2 1 x 150 Ampere 4 Gauge PK4, CK4
KXMA400.4 1 x 100 Ampere 4 Gauge PK4, CK4
RADIO
DETECT
12V
battery
external fuse
remote turn-on (see page 6)
≤7”
(18cm)
ABYC-compliant power terminals
Amplifi er uses 304-stainless steel screws
and conformal coated PCB for increased
weather resistance
aluminum bottom plate
